| Prod Model: |
TF35020A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 240*320 LCD Transparent Display: |
3.5inch with Sunlight Readable LCD Module |
| Type: |
TFT |
| Application: |
Graphic Design |
| Aspect Ratio: |
4:3 |
| Widescreen: |
Not Widescreen |
| Response Time: |
30ms |
| 3D: |
Not 3D |
| Feature: |
Transflective LCD Display |
| Optimum Resolution: |
240*320 |
| Screen Size: |
3.5inch |
| Interface Type: |
18 Bit Compatible RGB+Spi I/F |
Product Description
240*320 lcd transparent display with 3.5inch with sunlight readable lcd module TF35020A
Item: 240*320 lcd transparent display with 3.5inch with sunlight readable lcd module TF35020A
Resolution: 240*320
Inserting Mode: Put-in Type
Viewing Angle: 6: 00
Interface: 18 Bit compatible RGB+SPI I/F
Outline Dimension: 64mm(W)× 85mm(H)× 3mm(D
Active Area: LCD: 53.64mm(W) × 71.52mm(H)
Driver IC: --
PIN Nos.: 50
LED Connect Mode: 10 LEDs in parallel
Operating Voltage -0.3~4.6V
Operating temperature -20~70° C
Storage temperature -30~80° C
Backlight Luminance: 250CD/M2
LCM Luminance: 5000CD/M2
LCM Brightness Uniformity
--
We are professional TFT LCD manufacturer with our own factory in Shenzhen China. We have our own professional R&D groups specialized in a wide range from TN/STN/FSTN/OLED/Capacitive touch panel&Resistive touch panel/Plastic moulding customization. All the products produced in our company enjoys the most advanced production craft and technology as well as the strictly ISO quality management system which widely used in the mobile phone, car, industrial products, medical treatments and consumer area and so on.
