Creative Galaxy Electronic(SZ) Co., Ltd. >> Sumsang Multi-Screen LED Splicing Screen Display for Advertising 46''

Sumsang Multi-Screen LED Splicing Screen Display for Advertising 46''

Sumsang Multi-Screen LED Splicing Screen Display for Advertising 46''
Price: US $ 100-1000/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,Paypal
Network Support: Ethernet
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 6mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 27,777 dots / m²
Scanning Mode: 1/8 Scan
Display Type: LED Video Display
Application: Shopping Guide
IP Rating: IP43
System Operating Platform: Windows 7

Product Description

Main Indicators
Model NameSangsum 46'' multi-screen splicing screen
Physical PropertiesSize1022(W)×577(H)×109(D) mm
Lifespan60000h
Display ParametersTypeLED-backlit
Screen Portion16:09
physical Resolution1920×1080
Video FormatsNTSC;PAL;SECAM
Response Time8ms
 Display Color10bit -1 billion color
Brightness450cd/m2700cd/m2450cd/m2700cd/m2450cd/m2450cd/m2450cd/m2
Contrast3500:13500:14000:14000:13500:13500:11500:1
Dynamic Contrast10000:1
View Angle178/178 degree
InterfaceSignal InputHDMI/VGA/DVI/ Video/USB
Control Input/OutputRS-232(RJ45)
PowerMaximum Power180W210W175W210W210W210W230W
Standby Power0.5W0.5W1W0.5W1W0.5W0.5W
 Input PowerAC100V -240V~(+/-10%), 50/60Hz
Operating EnvironmentOperating Temperature0ºC~ 50ºC
  Operating   Humidity10%~ 90%
Splicing ParametersDisplay NumbersAny number
Splicing GapExtr-narrow edge
Stitching Seam3.5mm5.5mm6.7mm8mm10mm
Installation WayCabinet/wall hanging/landing steel/ hoisting
Rack MountingCustomize
Weight22KGS22KGS22KGS22KGS23KGS22KGS22KGS
Operating ModeManual/infrared remote control
Cooling SystemBuilt-in intelligent temperature control fan
Casing MaterialSheet metal steel
 Features1) Designed for video display, high brightness and high definition.
2) Cooperate with high-definition GPU and matrix,  support to 256 screen wall.
3)Adopt unique DID screen,  can be horizontally or vertically placed.
4)Outdoor machine has the function of automatic diagnosis, it can start the fan cooling or inside heating by juding the internal  temperature.
5)Long life, stable running, no injuries and damage, low maintenance cost.
6) Many kinds of  input/output interface, VGA, DVI, HDMI and AV interface terminal which  can be connected to the computer and various of video equipments.
7)New "ultra wide Angle extension technology" (S - PVA&S - IPS), guarantee the image without  deformation and the color without distortion up and down around 178 degrees.
8)Indicator light is real-time monitoring, temperature sensor,  built-in fan, video wall function, RS232 control loop.
