| Prod Model: |
QFI-3F |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East |
| Flake Ice Thickness: |
1.5mm - 2mm |
| Evaporating Temperature: |
-20 Deg. Celsius |
| Condensing Temperature: |
40 Deg. Celsius |
| Inlet Water Temperature: |
16 Deg. Celsius |
| Cooled Method: |
Air Cooled |
| Power Supply: |
3pH 380V/50Hz |
| Ice Capacity: |
3000kgs/Day |
| Refrigerant: |
R22/R404A |
| Condition: |
New |
| Ice Shape: |
Flake Ice |
Product Description
3ton flake ice maker
Commercial flake ice machine is small-sized products specially designed for clients who need less amount of ice. It has the advantages of small space requirement, easy maintenance and convenient relocation. The components of the machine are made up of stainless steel SUS304, aluminum alloy, and PE that are in good conformance with the international standard HACCP and FDA. The ice from this machine is very dry, pure, powderless, uneasy blocking. This machine and work constantly and efficiently for more than 10, 000 hours without any faults.
Capacity from 500kgs to 5000kgs per 24hrs;
The commercial flake ice maker is particularly suitable for refreshing vegetables and foodstuff in supermarket and quick cooling for processing fishery products and butchery.
Large ice making system is produced special for large-scale food-processing plant, aquatic plant, poultry slaughtering plant, chemical plant, bio-pharmaceutical and concrete mixing's ice requirement. The system mainly uses screw rotor compressor units or piston parallel units to achieve cooling. The cooling accessories contain separator, filter drying etc.
Capacity from 8000kgs to 60000kgs per hrs.
The large ice making system has been widely applied for the cooling process in fermentation, dairy production, chemical dyes, biological pharmacy, scientific experiment, mining temperature reduction, concrete cooling, hydroelectric power station, unclear power station, etc.
|
QFI-XF/XS Series Flake Ice Machine Technical parameters |
|
Model |
Capacity
(kg/24h) |
Refrigerating
capacity (KW) |
Total Power |
Cooling
method |
Unit Dimension
(L×W×D(mm) |
Weight
(kg) |
|
QFI-0.5F |
500 |
3.05 |
2.27 |
Air cooed |
1310×690×709 |
160 |
|
QFI-1F |
1000 |
6.25 |
4.21 |
1310×690×882 |
210 |
|
QFI-1.5F |
1500 |
8.15 |
5.42 |
1550×1000×970 |
330 |
|
QFI-2F |
2000 |
10.32 |
6.72 |
1550×1000×1020 |
360 |
|
QFI-2.5F |
2500 |
13.12 |
8.52 |
1550×1000×1050 |
390 |
|
QFI-3F |
3000 |
19.17 |
9.82 |
1550×1000×1130 |
470 |
|
QFI-5F |
5000 |
28.8 |
18.4 |
1850×1370×1373 |
1100 |
|
QFI-5S |
5000 |
28.8 |
15.28 |
Water cooled |
1850×1370×1373 |
1100 |
|
QFI-8S |
8000 |
43.2 |
22.79 |
2300×1650×1525 |
1300 |
|
QFI-10S |
10000 |
51.5 |
29.17 |
2300×1650×1745 |
1500 |
|
QFI-12S |
12000 |
79.0 |
42.0 |
2480×2000×1780 |
2000 |
|
QFI-15S |
15000 |
106.6 |
55.47 |
3200×2010×2061 |
3200 |
|
QFI-20S |
20000 |
113.6 |
65.57 |
3400×2180×2370 |
4200 |
|
QFI-25S |
25000 |
154.8 |
77.25 |
3800×2540×2452 |
5000 |
|
QFI-30S |
30000 |
184.5 |
92.4 |
4500×2540×2772 |
6000 |
|
QF-35S |
35000 |
219.5 |
108.35 |
4780×3010×2658 |
6500 |
|
QFI-40S |
40000 |
253.8 |
121.85 |
5000×3010×2818 |
7500 |
|
QFI-50S |
50000 |
329.1 |
160.15 |
5000×3010×3158 |
10000 |
|
QFI-60S |
60000 |
393.7 |
189.35 |
5500×3010×3358 |
12000 |
|
Standard ambient temperature: 25deg. Celsius; Water supply temperature: 16deg. Celsius; |
|
Refrigerant: R22, R404a. |
|
Power supply: 3PH 380V/50HZ/60HZ; 3PH 460V/60HZ; 3PH 230V/60HZ. |
