YTD-CD52 Mobile Phone Screen Protector Engraving Machine for Drilling Holes on Glass

YTD-CD52 Mobile Phone Screen Protector Engraving Machine for Drilling Holes on Glass
Price: US $ 12000/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: Ytd-CD52
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Machine Frame: Grantie
X Stroke: 370mm
Y Stroke: 500mm
Z Stroke: 100mm
Working Table Size: 700mm*500mm
Max Moving Speed: 18m/Min
Cutting Feed Speed: 9m/Min
Spindle Power: 1.8 Kw
Spindle Speed Range: 60000 Rpm
Type: CNC Engraving Machine / CNC Router
Certification: CE
Control System: Industrial Computer

Product Description

Ytd-CD52 Mobile Phone Screen Protector Engraving Machine for Drilling

Application:

Drilling Holes and carving the straight glass corner into be round corner.

Parameters:

Machine FrameGrantie
X Stroke370mm
Y Stroke500mm
Z Stroke100mm
Working Table Size700mm*500mm
Max Moving Speed18m/min
Cutting Feed Speed9m/min
Spindle Speed Range60000 RPM
Spindle Quantity2 spindles, can work independently
Repeat accuracy0.005mm
Positioning accuracy0.006mm
Tool setting accuracy0.002mm
Lubrication systemOil auomatic lubrication
Air Pressure0.5-0.65mpa
Table loading capacity120kg
Driving ModeAC Servo motor
Processing instructionG code
Control systemDELTA numerical control system
PowerAC220V  50Hz
Gross Weightabout 1800kg
Dimention1250*1400*1650mm
Rated Power5KW

Please note: Above parameters only for reference, we keep improving our machine, parameters might be different.

Configuration:

Machine FrameGrantieJinan Shandong
Control systemBaoyuan / WeihongTaiwan / Shanghai
X/Y Screw rodGrinding 2005Taiwan / Japan
Z Screw rod Grinding 2002Taiwan / Japan
X/Y Liner Guide20R2Taiwan / Japan
Z Liner Guide20R2Taiwan / Japan
Servo MotorMHMJ042GIUJapan Panosonic
Main Spindle6000RPMMotorized spindle(Aibeike, Dake, Shufeng)
Water cooling machineHigh precisionIndustial cooking Machine( Shenzhen)
Water pumpLDPB4-18-220VLuokai
Supporting End BearingDeep groove ball bearingJapan NSK
Fixed End BearingAngular contact bearingJapan NSK
Cutter Posotioning0.002mmTaiwan
SwitchD2VW-5L2-1MOmron
Converter1.5KWTaiwan


Packaging: Wood Case

What can YTD do for you?

YTD provide strong technology support for building screen protector plant.
YTD can provide you a whole production line for tempered glass screen protector and solutions as per your capacity.
YTD is your professinal consultant, you could consult us about materials, technology, production scheme, etc.

After-Sales Service

1. Free technical support, machine installment, machine operation and trouble shooting method.

2. Control system upgrade, motherboard upgrade, and related functions upgrade.

3. Supply free spare parts during warranty period.

4. One year warranty, except for artificial damage and wear parts.

5. 24 hours telephone technical support.

About us:
Shenzhen YTD Industrial Co., Ltd is a supplier that specializes in developing, designing and manufacturing all kinds of automatic machine.

We can supply complete tempered glass screen protector production line, such as glass cutting machine, polishing machine, engraving machine, tempering furnace and coating machine, etc.
We can send engineers overseas to install machines and train workers to help you build your plant.
Tell us what you need, machines, raw materials, technology, solutions, good after sales service?
Come to us, we have a professional team with rich experience to help you.

Quality policy: quality is our soul, we adhere strictly to ISO 9001 quality management system. We pay attention to every detail, take care of every detail, try our best to be excellent.

Excellent products, credibility first, win-win cooperation----- YTD will always be your most sincere partner.

FAQ

1. What is your lead time?
    3 to 4 weeks

2. What is your payment term?
    Negotiable.

3. How long is your guarantee?
    Usually a year

4. Can I visit your factory?
    We welcome you to visit our factory and we will pick you up from Airport in Shenzhen

5. What is the customs duty.
    It depends on your local customs policy, we can write either pratical amount or lesser amount on the invoive as per your request to help you reduce payment of customs duty.
