Guangzhou Hao Yang Pro Audio Manufactory >> Upgrated Fp14000 Switch Power Amplifier 4400W

Upgrated Fp14000 Switch Power Amplifier 4400W

Upgrated Fp14000 Switch Power Amplifier 4400W
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Paypal,Money Gram,Western Union
Prod Model: FP14000
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power: 14000W Peak
Size: 2u
Amplification Type: Passive
Speaker Material: Metal
Structure: Closed Enclosure Enclosure
Power Range: 4400q
Color: Black
Cinema Types: Wired
SNR: <70dB
Type: Switch
Usage: Karaoke, Stage/DJ
Sound Channel: 4 CH

Product Description

 upgrated Fp14000  Switch Power Amplifier:
2400W X 2 @ 8 OHMS
4400W X 2 @ 4 OHMS
7000W X 2 @ 2 OHMS



FP SeriesFP20000QFP9000FP14000FP6000QFP10000Q
8ΩStereo Power(RMS)2200WX41800WX22400WX2700WX41300WX4
4ΩStereo Power(RMS)4000WX43000WX24400WX21300WX42100WX4
2ΩStereo Power(RMS)5000WX44500WX27000WX21500WX42500WX4
Frequency Response(+o/-0.3dB,1W/8Ω)20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W<0.1%
Damping Factor1300
Signal-to-Noise Ratio>112 dBA
Channel separation (Crosstalk) at 1 kHz>70 dB
Input Connectors (per channel)3-pin XLR, electronically balanced
Output Connectors (per channel)Binding Posts 2-pole
ClassTD
TourClass ProtectionACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input
Operating voltage, 220 V / 100 V nominal220 V / 110 V selectable
Voltage Gain(dB)23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance20 kOhm
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)483×88×396mm
Packing dimension580×180×560mm
Net weight(kg)15
Gross weight(kg)18
