Product Description
MAIN FEATURES
Using UHF 700-870 MHz band to avert frequency interference
Automatic frequency scan feature searches for available frequencies.
PLL system, presel 16 non-interfered channels
SMTtechnology
Receiver use one 1.5V AA battery power supply
Handheld microphone rechargeable or use 1 5V AA battery
Ideal distance: 30m
Small and useful, easy to carry, the receiver directly connect to
6.35mm audio amplifier sl/stem to work
SPECIFICATION
Comprehensive Performance
Carrier Frequency: UHF700-870MHz
Frequency Stabilization: <± 30ppm
Dynamic Range: >100dB
Total Harmonic Distortion: <0.5%
Frequency Response: 40Hz-15Hz± 3dB
Audio Output Level: Unbalance 400mV
Receiver
Power Supply: DC15-17V
Consume Power: 1 WATT
Signal/Noise Ratio: >100dB
Image&Spurious Rejection: >80dB
Border Upon Channel Rejection: >80dB
Receiving Sensitivity: 5dBuV
De-Emphasis: 50uS
Handheld Microphone
Transmitter Power: 30mW
Modulation Type: FM
Deviation: 40KHz
Spurious Emission: >60dB
Battery Voltage: 3V (2x1.5V AA Battery)
Continuous Using: 5 hours
Our comapny is one of the most powerful microphone supplier in mainland China, and we leads the microphone market & technology; We have developed the first UHF wireless mics, the first true diversity receiver, the first LCD display, and the first auto-scan system etc.
We have acquired mature technical skills, abundant working experience, advanced manufacturing instruments( such as HP vector analyzer & communication testing instrument, Motorola high frequency testing instrument, SMT technology and so on), and modernized management. And for those reasons, our products are very popular and well-accepted in the whole world, our monthly average export amount has achieved 12, 000PCS last year.
