Leipasi Electronics Co., Ltd. >> Small Watt Professional Power Amplifier Ca2

Small Watt Professional Power Amplifier Ca2

Small Watt Professional Power Amplifier Ca2
Price: US $ 128/Piece
Min Order: 50/Piece
Pay Type: T/T
Prod Model: CA2
2u Class Ab Circuit: 21kg
Damping Factor: >400
Input Sensitivity: 0.775V/1.0V/1.4V
Type: Professional Amplifier
Usage: Hi-Fi
Used For: Professional
Tube Type: Transistor Amplifier
Function: Post Amplifier
Voltage: AC 220V
Conductive Mode: AB
Output Number: 2
Sound Channel: 2

Product Description

Small watt professional power amplifier CA2


Feature
1.CA series power amplifier use SMD technology
2.Superior materials like Toshiba and pure transformer
3.Mode selector is available for stereo,parallel and bridged-mono operation



Model
CA2CA4C6 CA9
Stereo power 8Ω2x150W2x250W2x400W 2x520W
Stereo power 4Ω2x225W2x375W2x600W 2x780W
Stereo power 2Ω2x270W2x500W2x800W 2x1040W
8Ω BLT450W750W1200W 1560W
4Ω BLT540W1000W1600W 2080W
Frequency Response5-20K+/-0.5dB
THD+N<0.05%@8Ω 1KHz 1/4Po
S/N Ratio
>92dB>94dB>96dB>96dB
Slew Ration20V/u S
Damping Factor>400
Crosstalk>60dB@8Ω 1 KHz
Input Impendance20KΩ(Balance)/10KΩ(Unbalance)
Input Sensitivity0.775V/1.0V/1.4V
ProtectOverheat short circuit,DC,limit and-softstart,Output relay-zero Current Switch,Intellctual Clip limiter
Gross Weight21KG23KG26KG 27.5KG



About us

Our Advantage                    1.We are professional audio factory, so we can provide the compitive price to you.
2.we focus on middle and high-end items and ensure every product made by  the the superior material. we have strict quality control system to avoid quality problems.
3.There are many types you can choose ,if you have you own designed idea,we also accept the OEM order
4.Little order is availiable
The Sample                                            About the sample, buyer need to charge the sample and freight fee.
The Shipping1.Express
2.Air shipping
3.Sea shipping
The Lead-time1.Small order and sample:5-7days
2.Big order:30-45 days
PaymentT/T (T/T:30% deposit before producing ,the balance paid before shippment)


Enping Leipasi Electronics Technology Co Ltd is professional audio manufacturer and our factory is located in Enping city, Guangdong, China. We are dedicated to manufacturing high qualityprofessional power amplifier, equalizers, crossovers and signal processors.

Over past years, we has earned great reputation among our partners by providing high performance audio products that is trusted but also maintaining a high level of service and after sales service.

We have been the manufacturer of professional power amplifier for years. We have the excellent technology and use the superior materials which are mostly imported from Japan, Korea and so on. We exported the amplifiers to all over the world, such as America, Japan, Thailand, ect.

There are many different series of products. Such as CA, CK, MT, FP, HA series. The watt range from 15W to 1500W. All series of our goods are high quality, stable and have a lower price, which can help you to reduce your cost and win your market.

OEM and ODM service are also offered to you. Together with the team of engineers, we are dedicated to research and develop new professional audioto keep up with current market's demand.

It is your good choice to choose our products, and it is going to be the pride of our company to build a business relation with you.
