Prod Model: |
GX1604B6FSB6K |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Driving Conditions: |
1/16duty 1/5bias 7V |
Connection Mode: |
COB |
Display Mode: |
Transflective/Positive |
Operating Temperature: |
-20~70 C Degrees |
Storage Temperature: |
-30~80c Degrees |
Screen Size: |
≤17" |
Application: |
Mobile Phone |
Aspect Ratio: |
16:10 |
Widescreen: |
Not Widescreen |
Response Time: |
30ms |
3D: |
Not 3D |
Feature: |
No Touch Panel |
Optimum Resolution: |
132*32 |
Type: |
FSTN |
Interface Type: |
COB |
Product Description
Display Color positive/Transflective
Drive IC:ST7066U-0A&ST7063C&ST7065C
Interface Input DATA: 4-bit or 8-bit Parallel Interface MPUl
Delivery Term:45 days
Display mode:FSTN
The thickness of single glass:0.4t.
Viewing direction | 6 O'CLOK |
Module Size | 87.0(W)*60.0(H)*14.0Max(T) |
Viewing area | 61.7Min(W)*25.2Min(H) |
Resolution | 132*32 |
Effective display area | 56.2(W)*20.8(H) |
Dot size | 0.55(W)*0.55(H) |
Dot Pitch | 0.60(W)*0.60(H) |
Driving voltage of LCD | 7.0V |
