Professional Amplifier (FP14000) , PRO Amplifier, Audio Amplifier

Professional Amplifier (FP14000) , PRO Amplifier, Audio Amplifier
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union,Money Gram
Prod Model: FP14000
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Power: 20-20kHz, 1W with 1 kHz
RMS: 4400W
Colour: Black
Model: Fp14000
Usage: Outdoor
Used For: Professional
Tube Type: Transistor Amplifier
Function: Post Amplifier
Sound Channel: 2.1
Output Number: 4
Voltage: AC 220V
Element Number: Push-Pull Amplifier
Conductive Mode: D

Product Description

FP14000 power Amplifier
2-channel
8ohm Stereo Power(RMS): 2400WX2
4ohm Stereo Power(RMS): 4400WX2
2ohm Stereo Power(RMS): 7000WX2

Features:
1:  FP series is uses new FM-wide regulator  would be get more  power    technology. It is a small size ,low weight and high efficiency ,high power and high reliability. Both mobile and fixed installation performance are the best choice for you .

2: Fidelity output:
High-efficiency amplifier output circuit , small size ,high power density,Hifi-lever tone .

3: Perfect protection system:
It has full function protection, it includes power soft start,overload and short circuit,DC, overheating ,UHF, clipping limiter function,especially without output relay protection, it has reflected the rapid,accurate, is the relay cant not be compared.




Model
FP14000
Output Power20-20kHz, 1W with 1 khz
8ΩStereo Power(RMS)2400WX2
4ΩStereo Power(RMS)4400WX2
2ΩStereo Power(RMS)7000WX2
8ΩBridged Power(RMS)8800W
4ΩBridged Power(RMS)14000W
Frequency Response(+o/-0.3dB,1W/8Ω)20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W<0.1%
Signal-to-Noise Ratio>112 dB
Channel separation (Crosstalk) at 1 kHz>70 dB
Input Connectors (per channel)3-pin XLR, electronically balanced
Output Connectors (per channel)Binding Posts 2-pole
ClassTD
TourClass ProtectionACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input
Operating voltage, 230 V / 115 V nominal130-265 V / 65-135 V selectable
Voltage Gain(dB)23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance20 kOhm
Level adjustment (per ch.)Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W×H×D)483×88×396mm
Packing dimension560×180×500mm
Net weight(kg)15
Gross weight(kg)18


Guangzhou Hao Yang PRO Audio Manufactory was founded in 1998, a number of its brands; Agent and a number of famous foreign brands, such as: The United States, Factory is a specialized professional stage doing fine speaker, professional audio equipment and digital audio system for R & D and production, sales in one of the producers; Warm service units in order to survive, quality assurance, stability, technological innovation and development, domestic and foreign customers for the cost-effective professional audio equipment.

Professional audio equipment factory targeted for its strong and took advantage of a variety of applications, According to the designers of the product adaptation to different characteristics of the product structure and configuration of the different functions of the formation of a series of widely used in high-end KTV, theaters, sports venues, outdoor performances, nightclubs, indoor SHOW it, the stage bars, Multi-function hall and many other places use the product line. Our products may not be the best, but our product is the most applicable, the most reliable, most cost-effective!

At the same time, in the bigger, stronger, do a good job in their own brand names outside the factory for domestic and foreign customers with OEM, ODM services for customers with special needs box processing services.
