pH10 Outdoor Full Color LED Display for Advertising

pH10 Outdoor Full Color LED Display for Advertising
Price: US $ 935-943/Square Meter
Trade Terms: FOB,EXW,CIF
Min Order: 5/Square Meter
Pay Type: T/T,Western Union,Paypal
Prod Model: PH10 SMD3535 black lamp outdoor led display
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 160mm*160mm
Module Resolution: 16*16
Cabinet Size: 960*960*160(mm)
Cabinet Resolution: 96DOT*96DOT for Real
Cabinet Pixels: 9216 Dots
Material: Iron
Cabinet Weight: 50kg for Iron Cabinet; 40kg for Aluminum Cabin
Brightness: More Than 5500CD/Sqm
Module Weight: 1.2kg
Warranty: 2 Years
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Pitch: 10mm
Pixel Configuration: 1R, 1G, 1B
Display Function: Market Display
Average Power Consumption: 300W / m²
Pixel Density: 10000 dot / m²
Scanning Mode: 1/4 Scan
Display Type: LED Video Display
Application: Advertising
Certification: CCC

Product Description

Product Features

 LED display has been widely adopted in this century compared to the conventional technology that has allowed for further enhancement, integration and various applications in the different environment.

 The deployment of LED as the display elements in the various applications as it able to produce various colors combinations, energy savings, integration ability, high luminance, longer life span, low maintenance, low heat generation, weather proof design, high temperature & UV resistant, true color emission, clear visibility, longer distance viewing and wider viewing angle.

 Nowadays, turning to SMD as the technology for LED display products is the market trend. OIC is one of the most pioneering companies who adopts and professional on SMD technology. Mainly we are using 3528 and 3535 types, and 3528 means that the encapsulation size is 3.5*2.8 mm while 3535 means 3.5mm*3.5 mm. SMD can be both of indoor, outdoor using and SMD module.



LED Parameters

Item

Luminous Intensity

Viewing Angle(H/V)

Wavelength

Test Condition



Red LED

500-900mcd

120º/120º

620-630nm

25ºC,20mA

Green LED

1800-2200mcd

120º/120º

520-535nm

25ºC,20mA

Blue LED

250-500mcd

120º/120º

465-475nm

25ºC,20mA



Module Parameters

Pixel Pitch

10mm



Pixel Configuration

1R1G1B SMD 3in1

Module Resolution

32dots*32dots for real

Module Pixels

256 dots

Module Size

320mm*320mm

Module Weight

1.2KG



Cabinet Parameters

Cabinet Size(W*H*D)

960*960*160(mm)



Cabinet Resolution

96dot*96dot for real

Module Quantity

9 pcs

Cabinet Pixels

9216 dots

Pixel Density

10000 dot/sqm

Avg. Power Consumption

250W/sqm

Max. Power Consumption

750W/sqm

Material

Iron or Aluminum

Cabinet Weight

50KG for iron cabinet;
40KG for aluminum cabinet



Screen Parameters

Brightness

≥5500cd/sqm

Contrasts (Max. /Min.)

1.1:1

Driving Method

1/4 scan

View Angle

Horizontal 120° Vertical 120°

Optimal Viewing Distance

10m to 100m

Brightness Control

Red, Green and Blue 256 Grade/Each

Fresh Frequency

≥600Hz

Frame Frequency

50 - 60Hz

Input Voltage

AC220V/50Hz or AC110V/60Hz

Defects Rate

≤0.00001

Screen Weight

≤65kg/sqm for Iron cabinet /45kg/sqm for Aluminum cabinet

MTBF

>10,000 hours

Life Span

≥100,000 hours

Brightness Uniformity

<3%

Earth Leakage Current

<3mA

Protective Grade

IP65

Temperature-operating

-40°C~60ºC°C

Humidity-operating

10%~90%

Operating System

Windows98/me/2000/NT/XP/win7


Shenzhen Noveled Technology Co., Ltd ( Noveled ) is a subsidiary of Noveled Group Co, Ltd...Noveled is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays. & LED lighting...

With several years of development, NOVELED own its factory workshop area about 2, 000sqm, professional clean room, Siemens high-speed placement machine, automatic plug Universal, computer intelligence environmentally friendly lead large wave soldering, reflow (8 for 8 microcirculation heat treatment technology), Intelligent glue large stroke machine., monthly capacity is 1000sqm We are an ISO 9001: 2000 company, CE certified, export licence holders. We have the honor to work for hundereds of customers in over 400 cities of 33 provinces in China, and we also have built long-term business relationship with the customers all over the world, for example, PCS Sound in Austria, Screen world in Korea, Mega LED in Turkey, Internacionmidia in Brazil and so on.

NOVELED products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.

We adhere to the "customer first, quality first, reputation first, " as operating principle. Our assurance is to provide our customers best products with high quality and most reasonable prices above your level of satisfaction.
