Prod Model: |
p5/SMD 3in1 |
Cabinet Size: |
640mmx640mm |
Lifespan: |
100000 Hours |
Module Size: |
320mm*160mm |
Delivery Time: |
7-10 Working Days |
Cabinet Pixel: |
128X128dots |
Brightness: |
>1600CD/M2 |
Optimal Viewing Angle: |
160°(W) 120°(H) |
Working Voltage: |
220VAC |
Control Mode: |
Synchronization with PC |
Optimal Viewing Distance: |
5-30m |
Tube Chip Color: |
Full Color |
Display Function: |
Video Display |
Pixel Pitch: |
5mm |
Pixel Configuration: |
1R,1G,1B |
Pixel Density: |
40,000 dots / m² |
Scanning Mode: |
1/16 Scan |
Display Type: |
LED Video Display |
Application: |
Shopping Guide |
Certification: |
FCC,EMC |
System Operating Platform: |
Win98/2000/Nt/XP |
IP Rating: |
31 |
Product Description
Product Description
Mountain A-Li Group Electronic Company
Professional development manufacturing LED display system products and lighting products, was founded in 2000, own workshop area 20000 m2, branch office and agents cover all over China, with about 300 employees.
Product features:
1.Energy saving design, good cooling system, high definition,
2.Cost-effective, outstanding reliability, complete function,
3.Are favorite by new and old customers
4.Ultra-high refresh rate, can support video shooting,
5.Clear picture quality assurance
6.Quick and easy assembly, removing System, save loading time
Application
Widely used in a variety of needs large hall,sports arena,banking,telecommunications,government agencies,terminal,pier,railway stations,the stock market and other trading market,medical systens,electric power,galleries and other publicity,advertising,information dissemination,the guide places .
Market:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Parameters
The specifications of modules | |
|
Items | Parameter | |
Product Model | P5 Indoor Full Color LED Module | |
Module size | 320mm*160mm | |
Pixel pitch | 5mm | |
Pixel density | 40000dots/m2 | |
Pixel configuration | 1R1G1B | |
Module resolution | 64dots(W)*32dots(H) | |
Module maximum power consumption | 25W | |
Module Thickness | 14.275mm()26,6() | |
Module Weight | 0.21kg | |
Driving method | Constant Current Driving | |
Scanning method | 1/16scan | |
Interface | HUB75-A | |
Brightness | ≥1600cd/m2 | |
The specifications of cabinets | |
|
Cabinet size | 640mm*640mm | |
Module quantity | 16pcs | |
Power supply | 5V/40A 5V/60A | |
Cabinet resolution | 128*128dots | |
Optimal viewing distance | 5M~30M | |
Optimal viewing angle | 160°(W) 120°(H) | |
RH Working temperature | (Work :-20°C~+60°C) | |
System operating humility | 10%-95% | |
The specifications of power supplier | |
|
Operating Voltage | AC220V±10% | |
Average power consumption | 270W/H | |
Maximum power consumption | ≤500W/m2 | |
Electric current | ≤20mA(single LED) | |
The specifications of control card | |
Control Panels | Pentium4 or above | |
Operating system | WIN98/2000/NT/XP | |
Control model | Synchronization with PC | |
The specifications of the main technical parameters | |
|
Driving device | Constant Current Driving | |
Refresh rate | ≥400HZ | |
Grey scale | RGB Each 256, can display 16.7M colors) | |
MTBF | ≥9000hours | |
Power switch | Automatic Switch | |
Display Mode | 800*600/1024*768 | |
Certificates
HongKong Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.
Features:
1) With good lightening accordance and no mosaic
2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Applications:
LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
