Prod Model: |
P25 outdoor |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Highbright Ness: |
7500CD |
Module Size: |
200mmx200mm |
Standard Cabinet: |
1000mm X 1000mm |
Intalltaiton Manner: |
Fix Intallation |
Broadcast Format: |
VGA, Video ,AVI |
Tube Chip Color: |
Full Color |
IP Rating: |
IP65 |
Pixel Pitch: |
25mm |
Pixel Configuration: |
2R, 1G, 1B |
Display Function: |
Video Display |
Average Power Consumption: |
220W / m² |
Pixel Density: |
1600 dot / m² |
Scanning Mode: |
Static Scan |
Display Type: |
LED Video Display |
Application: |
Advertising |
Certification: |
CCC |
Product Description
P25 outdoor LED Display
Noveled Group Co. Ltd is the leading OEM manufacture of LED Display Screens and LED light in China...We can supply LED Display, LED Screen, LED Sign, LED Video Display, Full color indoor LED display, Full color outdoor LED dislay. LED Panel, LED billboard, LED advertising display, LED display board, LED display module.
1) We make the whole produce process under the anti-static control, to prevent the harm of static and reduce the rate of burning out. Now the dead DOT rate of our outdoor LED display can be controlled within 1/10, 000.
Product Description:
Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously.
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via LAN and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
Specification | Parameter |
Pixel Pitch | 25 mm |
Pixel composing | 2R1G1B |
Density per sqm | 1600 pixel |
LED package | DIP 546 |
Wavelength(R) | 625~630nm |
Wavelength(G) | 525~530nm |
Wavelength(B) | 470~475nm |
Led Lamp type | Nichia/Cotco-Cree/Silan |
Module size | 200 mm*200mm |
Display resolution/module | 8 dots*8 dots |
Standard cabinet size | 1000*1000mm |
Weight per sqm | 70Kg/sqm |
Protection classification | IP65 |
Wave Angle (H) | 140° (H)/ 60° |
Display color | 256*256*256 |
Whiteness brightness | ≥ 5000 |
Changing frame frequency | 60 Hz |
Refresh | 400 Hz |
Driving method | Constant Static |
Control way | Real or Virtual Pixel |
Max power/sqm | 500W/sqm |
Average power/sqm | 200W/sqm |
Working voltage | AC 220± 10%50Hz or AC 110± 10%60Hz |
Short circuit protection | Yes |
Working temperature | -20~50 centigrade |
Working Humidity | 10~90% |
Out of control | 1/10, 000 ( scattered) |
Lifetime | 100, 000 hours |
Environment | Outdoor |
Install mode | Wallmount, upright post |
Control mode | Synchronous |
Display port | DVI |
Display mode | 1024*768 /1024*1024 |
Shenzhen Noveled Technology Co., Ltd ( Noveled ) is a subsidiary of Noveled Group Co, Ltd...Noveled is a national level and high & new technology enterprise which specialize in designing, researching, manufacturing and selling all kinds of LED displays. & LED lighting...
With several years of development, NOVELED own its factory workshop area about 2, 000sqm, professional clean room, Siemens high-speed placement machine, automatic plug Universal, computer intelligence environmentally friendly lead large wave soldering, reflow (8 for 8 microcirculation heat treatment technology), Intelligent glue large stroke machine., monthly capacity is 1000sqm We are an ISO 9001: 2000 company, CE certified, export licence holders. We have the honor to work for hundereds of customers in over 400 cities of 33 provinces in China, and we also have built long-term business relationship with the customers all over the world, for example, PCS Sound in Austria, Screen world in Korea, Mega LED in Turkey, Internacionmidia in Brazil and so on.
NOVELED products widely used in outdoor advertising, cultural and recreational activity, stadium, stage background rental, With its full color LED displays advantages, from the design, productions, installation to the maintenance, Use of comprehensive integration solutions, effectively reduce the overall cost for customers, so as to create more value for customers.
We adhere to the "customer first, quality first, reputation first, " as operating principle. Our assurance is to provide our customers best products with high quality and most reasonable prices above your level of satisfaction.
