| Prod Model: |
WVT-M10R-46 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Status: |
Stock |
| Response Speed: |
8-25 Ms |
| Touch Points: |
10 Touch Points |
| Altitude: |
up to 3, 000m |
| Available Sizes: |
32'' to 65'' |
| Driver: |
Windows 7 |
| Warranty: |
1 Year |
| Operation System: |
Windows 7 |
| Agency Approvals: |
CE, FCC, RoHS |
| Kind: |
Multi Touch |
Product Description
Touch Screen Panel
Multi Touch Screen Panel Overlay, Infrared Multi Touch, Windows7 Multitouch Screen
1. Main Features:
* Touch points: 10 touch points at a time
* Available Size: 32'' to 65''
* Supports Win7 and TUIO Protocal
* 1 year free warranty
2. Applications
*Point-of-information kiosks, Desktop touch monitor
*Electronic catalogs, Ticket machine
*Gaming, POS, ATM, lottery, and amusement
*Industrial control rooms
*Computer-based training
*In-vehicles and transportation
*Medical instrument
3. Advantages:
*Available size range from 32'' to 65". Customize upon requests from customer for any format display.
*Truly supports 10 precise touch points simultaneously without any ghost points.
*Compatible with windows 7, fully supports TUIO protocol in all-round way.
*USB connection to PC; Extremely low power consumption.
*Anti-Ambient Light; Performs greatly even in disadvantaged environments including all indoor activities and even under strobe lights in clubs.
*Effortless drags with refresh only 8-25 ms response time.
4. Certification:
*CE, RoHS
|
Size |
|
General Size |
32 inch to 65 inch |
|
Fit in with |
Panel display device |
|
Performance |
|
Touch Mode |
Multi-touch |
|
Resolution(Interpolation) |
4096*4096 |
|
Linearity Error |
<1.5mm |
|
Response Speed |
8-25ms |
|
Mechanical |
|
Input Method |
Finger or gloved hand (rubber ,cloth or leather) |
|
Touch Times |
Unlimited |
|
Touch Activation Force |
No minimum touch activation force is required |
|
Minimum Touch Object |
2.5 mm X 2.5 mm |
|
Vandal-proof |
No break by 1-pound steel ball dropping from 130 cm high |
|
Optical |
|
Glass: |
Without glass |
|
Light Transmission |
92% |
|
Gloss |
Antiglare surface (curved or flat): 95 ± 15 gloss units or 65 ± 15 gloss units |
|
Environmental |
|
Temperature |
Working Temperature 0°C~+60°C,10%-90%RH |
|
Storage Temperature: 0°C~+85°C,10%-90%RH |
|
Relative Humidity |
Operating Range: 0%~90% RH (no dew falls) |
|
Storage Range: 0% to 95% RH (no dew falls) |
|
Altitude |
Up to 3,000m |
|
Ambient Light |
Direct sunlight 90°to ±30° to the display surface Touch detection operational |
|
Direct sunlight all angles to display surface Free of false touch reports |
|
Electrical |
|
Operation Voltage |
Typical +DC 5V, +4.75V to +5.25V |
|
Power Supply |
Size under 52”(include 52”)USB or PS/2 Interface, power ripple max.200mV rms |
|
Size above 52”(52” not included): external AC-DC power adaptor |
|
Interface |
Full Duplex USB 2.0 (Full Speed) Plug and play compatible |
|
Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity |
|
Current |
Typical 150MA@+5VDC; 350mA, maximum |
|
Power |
<1.5W, operating current<300mA |
|
Electrostatic Protection |
15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4) |
|
Controller |
Integration inside touch panel |
|
Agency Approvals |
CE, FCC, Rohs |
|
Operating System |
|
Operation System :windows 7.TUIO Protocol |
