Icesnow Ice Flake Machine With Storage Bin for Cooling Food (400kg/ day)

Icesnow Ice Flake Machine With Storage Bin for Cooling Food (400kg/ day)
Price: US $ 5000-65000/Set
Trade Terms: base on request
Min Order: 1Set
Pay Type: L/C,T/T
Prod Model: GM-04K
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cooling Type: Air Cooling/Water Cold/Evaporative
Material Of The Evaporator: Stainless Steel or Carbon Steel
Quality: Top Quality and Superior Perfomance
Type: Concrete Flake Ice Machine

Product Description

Icesnow flake ice machine/ ice machine/ ice maker:

- Stability&reliablility, making flake ice in several minutes

- Long use life and environmental-friendly

- User-friendly design

- Fast cooling

Feature:

1. Power supply: 3P/380V/50Hz(design along with customer's request)

2. Fully Automatic and safe operation system

3. Flake Ice Thickness Range: 1.8-2.5 mm

4. Daily output: 350kg/24h~50000kg/24h, You can choose the different types to meet yourrequest.
5. Cooling type: Air-cooled, Water-cooled and evaporative
6. Refrigerant: R22/R404A/R407c

7. Reliable&famous compressor: Bizter/ Danfoss/ Copeland/ Hanbell,

It remain top quality and reliable performance with good daily output

8. Material of flake ice evaporator: Stainless steel or carbon steel (based on customer's request. )

9. Relatively big contact area and good mobility can ensure their full contact with refrigerated objects to realize good preservation effect;

10. Without any acute edges and corners, ice flakes do not damage the surfaces of refrigerated objects but extremely benefit for storage and delivery anywhere anytime;

11. All our equipment are convenient and easy to operate, strong adaptability and stable quality.

12. High quality and high capacity, but competitive price.

Advantages:

1. Perfect in cooling food;

Flake ice is dry and crispy, so it hardly has any shape edges, in food cooling process, which has made it the best cooling material. It reduces the damage to food to the lowest rate.

2. Thoroughly mixing;

Flake ice can become water quickly through the rapid heat exchanging with products, thus supplying the needed moisture to cool the products.

3. Small footprint, low noise, energy-saving, environmental friendly.

Application:

ICESNOW large and medium-sized flake ice machine has Large contact area with low cost of producing, flake ice can cool down the temperature at a fast speed and convenient for delivery, it was widely used in large shopping malls, aquatic products processing plants, engineering and construction, pre-cooling temperature, man-made ice project and other large products.

Flake ice machine model: Different from GM-30K, GM-035, GM-04K, GM-05K, GM-06K, GM-08K, GM-10K, GM-12K, GM15K, GM-20K, GM-25K, GM-30K, GM-40K, GM-50K, GM-80K, GM100K, GM-120K, GM-150K, GM-200K, GM-250K, GM-300K, GM-400K, to GM-500K,

Capacity: Different from 350kg/24hs-50000kg /24h
For the flake ice machine Model GM-04 K is: 400kg/24h

Compare to other supplier of flake ice machines in the industry, ICESNOW ICE SYSTEM owns its unique technology and has mush more better performance.

Description:

1. Superb Stability and reliability, long use life. Energy-Saving and cost-saving.

2. User-friendly design, intellectualized PLC touch-screen controller
The intellectualized PLC touch-screen control system, user-friendly designed, which is very convenient for operator. The intellectualized historical failure record Function and guidance of troubleshooting makes easier and simple operation and maintenance. The Running time setting function is convenient for operation.

3. Sub-cooled ice, excellent fast cooling
Super cold, dry, crisp, 100% subcooled ice with greater surface area and exceptional cooling power.

4. Low maintenance and operation cost
Super performance offers trouble-free operation, with much less maintenance probability than other brands of ice flakers.
Model daily output(kg/24h)


Bin capacity(kg)
Ref. capacity(kcal/h) Evaporating Temperature
(degree)
Total power(kW)

Power supply Re-frigeration Cooling mode Size
L*W*D(mm)
Bin size
L*W*D(mm)

weight(kg)
GM-035K 350 200 1961 -20 2.7 3p/380v/50Hz R404A
air cooling
1050*740*710 1050*970*900 196
GM-04K 400 300 2241 -20 2.7 3p/380v/50Hz R404A
air cooling
1235*740*710 1270*1030*1050 205
GM-05K 500 300 2801 -20 2.7 3p/380v/50Hz R404A
air cooling
1235*740*710 1270*1030*1050 205
GM-06K 600 300 3362 -20 3.0 3p/380v/50Hz R404A
air cooling
1235*740*710 1270*1030*1050 215
GM-08K 800 300 4482 -20 3.5 3p/380v/50Hz R404A
air cooling
1235*740*810 1280*1050*1060 240
GM-10K 1000 400 5603 -20 4.5 3p/380v/50Hz R404A
air cooling
1290*970*860 1330*1250*1210 295
GM-12K 1200 400 6724 -20 5.0 3p/380v/50Hz R404A
air cooling
1290*970*940 1330*1250*1210 340
GM-15K 1500 400 8405 -20 8.3 3p/380v/50Hz R404A
air cooling
1290*970*940 1330*1250*1210 360
GM-20K 2000 500 11206 -20 9.7 3p/380v/50Hz R404A
air cooling
1500*1100*1140 1520*1320*1300 420
GM-25K 2500 500 13541 -20 9.7 3p/380v/50Hz R404A
air cooling
1500*1100*1240 1520*1320*1300 440
GM-30K 3000 1200 16810 -20 11.2 3p/380v/50Hz R404A
air cooling
1800*1135*1240   550
GM-30K 3000 1200 16810 -20 11.2 3p/380v/50Hz R404A
air cooling
1800*1135*1240   550
GM-40K 4000 2500 22413 -20 15.1 3p/380v/50Hz R404A
Water cold
1650*1555*1330   820
GM-50K 5000 3000 28017 -20 18.0 3p/380v/50Hz R404A
Water cold
1650*1555*1530   1050
GM-80K 8000 5000 44827 -20 30.5 3p/380v/50Hz R404A
Water cold
2230*1890*1550   1280
GM-100K 10000 6000 56034 -20 31.0 3p/380v/50Hz R404A
Water cold
2230*1890*1670   1360
GM-120K 12000 8000 67241 -20 42.1 3p/380v/50Hz R404A
Water cold
2480*2000*1780   1530
GM-150K 15000 8000 84502 -20 56.0 3p/380v/50Hz R22
Water cold
3400*2080*1900   2820
GM-200K 20000 12000 112068 -20 63.0 3p/380v/50Hz R22
Water cold
3400*2080*2200   3650
GM-250K 25000 15000 140086 -20 78.3 3p/380v/50Hz R22
Water cold
3400*2080*2240   3980
GM-300K 30000 15000 168103 -20 102.5 3p/380v/50Hz R22
Water cold
4580*2770*2420   5000
GM-400K 4000 20000 224137 -20 124.3 3p/380v/50Hz R22   4580*2770*3000   5500
GM-500 50000 25000 280172 -20 147.4 3p/380v/ R22 Water 4580*27   630
Shenzhen Icesnow Refrigeration Equipment Co., Ltd. is a high-tech enterprise and professional manufacturer of refrigeration equipment and system which specialized in researching, designing, producing and trading of industrial and commercial refrigeration technology and facilities of ice flake machine. The company owns the first-class equipment, advanced manufacturing workmanship and complete testing method as well as modern management mode. Now we have launched 3 series ice flake machines covering 16 types, with its daily output ranging from 400kgs to 50ton, which greatly satisfied the increasing demands on the commercial ice and industrial ice. Our products are widely used in hyper market freshing, food processing, ocean fishery, Chemicals and dyeing, bio-pharmacy and laboratories.

Icesnow ice system, with its main parts imported abroad, is elaborately designed and has a superior performance. For the whole system is automatically controlled by microcomputer, so it's extremely easy and simple for operation. And the bin cylinder is our patented product, which ranks a leading level and gains widely reputation in and abroad.

First-class products, continuous innovation, durative improvement and clients satisfaction is our tenet. Excellent quality product, complete service and reasonable price is our persistent principle to hold market. We believe our sincerity and seeking-better altitude deserves your trust.
