Fp10000q Professional Digital Power Amplifier, Perfect for Line Array or Top Speaker

Fp10000q Professional Digital Power Amplifier, Perfect for Line Array or Top Speaker
Price: US $ 900/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T,Paypal,Money Gram,Western Union
Prod Model: Sanway FP10000Q
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Function: Amplifier Combined
Tube Type: Transistor Amplifier
Voltage: AC 220V
Element Number: Monoamplifier
Output Number: 4
Used For: Professional
Usage: KTV System
Sound Channel: 4.1
Conductive Mode: Td Class

Product Description

4x2500W 2ohm Switching Supply Power Amplifier ( FP 10000Q)

1. 4x2500W@2ohm Audio Power Amplifier
2. Lightweight Switching Power Amplifier
3. FP10000Q High Power Amplifier Audio

KEY FEATURE

1). Switching power supply
High efficiency and stability of the new switching power supply so that the signal transmission speed faster and more stable voltage changes, sensitivity stronger, lighter weight.
2). Intelligent signal limiter
Each channel has an independent output signal overload distortion, automatic pressure limited function, when the output signals are now clipping distortion can be quickly restored to the output signal compression is not the biggest distortion level and no reduction in the frequency response of audio signals, to avoid DC level because of the audio signal output and burned speakers.
3). Multiple detection, multiple protection
A soft start, the second start, the (low) pressure protection, output overload and short circuit protection.
4). High efficiency, low fever
Efficient Class TD amplifier, significantly reduce heat loss.
5). Pristine audio
Metal Packaging, high-power transistors, Yanyi a pure, passionate, authentic audio effects.
6). Removable face Network
Removable the hole into the wind-net, easy cleaning.




Specifications:
FP10000Q Professional Digital Power Amplifier, Perfect for Line Array or Top Speaker
ITEM FP10000Q
Output Power 20-20kHz, 1W with 1 KHz
8Ω Stereo Power(RMS) 1350WX4
4Ω Stereo Power(RMS) 2100WX4
2Ω Stereo Power(RMS) 2500WX4
8Ω Bridged Power(RMS) 4200WX2
4Ω Bridged Power(RMS) 5000WX2
Frequency Response(+o/-0.3dB, 1W/8Ω ) 20 Hz - 34 kHz
THD 20 Hz - 20 kHz for 1 W < 0.1%
Signal-to-Noise Ratio > 112 Dba
Channel separation (Crosstalk) at 1 kHz > 70 dB
Input Connectors (per channel) 3-pin XLR, electronically balanced
Output Connectors (per channel) Binding Posts 2-pole
Class TD
TourClass Protection short circuit, DC voltage, turn-on/off transient, current, inrush
Operating voltage 130-265 V / 65-135 V selectable
Voltage Gain(dB) 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance 20 Kohms
Level adjustment (per ch. ) Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (W× H× D) 483× 88× 396mm
Packing dimension 580× 180× 560mm
Net weight(kg) 13
Gross weight(kg) 18
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.

With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.

Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.

Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.

Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.

We always keep and follow the principle to do business:

The same product, we win by the quality;

The same quality, we win by the price,

The same price, we win by the service.

We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.

Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
