| COOLING X - Manufacturer Code |
| TRF-25BIA | TRF-25BIAA |
| Product identification |
|
|
|
| Description of appliance (Combi, Double Door, One door, Table Top, etc) |
| Double Door | Double Door |
| Type/appliance (Refrigerator, Larder, Freezer, Wine cooler, Beverage cooler) |
| Refrigerator | Refrigerator |
| FS (free standing) - BI (built-in) - BU (built-under) |
| BI | BI |
| Aesthetics |
|
|
|
| Door profile ( F = flat / R = rounded / etc...) |
| F | F |
| Handle (External/Metal/Integrated) |
| Integrated | Integrated |
| Available colours |
| white | white |
| Basic features |
|
|
|
| Energy efficiency class |
| A | A+ |
| Climate class (SN=10~32° C, N=16~32° C, ST=18~38° C, T=18~43° C) |
| N | N |
| Freezer compartment star rating |
| 4 STARS | 4 STARS |
| Energy consumption / year | kWh/year | 278 | 230 |
| Energy consumption (EN153) per 24 h | kWh/24 h | 0.76 | 0.63 |
| Energy Efficiency Index (Directive 2003/66/EC and the EN 153) |
|
|
|
| Gross capacity | l | 226 | 226 |
| Net capacity | l | 222 | 222 |
| Net capacity fridge compartment | l | 182 | 182 |
| Net capacity freezer compartment | l | 40 | 40 |
| Freezing capacity / 24 hours | kg/24 h | 2.0 | 2.0 |
| Max noise level | dB(A) | 42 | 42 |
| Max storage time by power failure Freezer | h | 11 | 11 |
| Kind of coolant (R134a/R600a) |
| R600a | R600a |
| Foaming components (R141b / R134a / C-P) | PU/ | C-P | C-P |
| Approvals (VDE / TÜ V / IMQ / NF / Ö VE / DEMKO etc. ) |
|
|
|
| Certifications ( CE / ISO 9001/2 / LGA etc. ) | CE | CE | CE |
| Key features |
|
|
|
| Cooling system: (K = Compressor / A = Absorbtion) |
| K | K |
| Number of compressor(s) |
| 1 | 1 |
| Defrosting Fridge / Freezer (M=manual A=automatic) |
| M | M |
| Control system (E = Electronic / M = Mechanical) |
| M | M |
| Fuzzy logic |
| NO | NO |
| NO FROST (Fridge/Freezer) |
| NO | NO |
| Wind Air System (Active Cooling / fridge only) |
| NO | NO |
| Bacteria Proof System |
| NO | NO |
| Control panel |
|
|
|
| External control display |
| NO | NO |
| External control display with LCD |
| NO | NO |
| to) " > Temperature range (from> to) | ° C | 0~10/ < -18º C | 0~10/ < -18º C |
| Super Cooling (Fridge) |
| NO | NO |
| Super Freezing (Freezer) |
| NO | NO |
| Holidays function (Stand-by) |
| NO | NO |
| ECO function |
| NO | NO |
| Over temperature alarm (Red lamp / LCD-LED / Acoustic) |
| NO | NO |
| Adjustable thermostat (Y=Yes / N=No) |
| Y | Y |
| Control lamps (Green / yellow / red) |
| NO | NO |
| Basics datas |
|
|
|
| Unit dimensions with-out handle ( H / W / D) | cm | 144X54X54 | 144X54X54 |
| Depth with open door | cm | 105.7 | 105.7 |
| Net weight | kg | 55.0 | 55.0 |
| Voltage / frequency |
| 220-240V/50Hz | 220-240V/50Hz |
| Input power / mains fuse (intensity) | W /A | 110 | 110 |
| Fridge compartment |
|
|
|
| Shelves: |
|
|
|
| Number/type | n° | 4 / glass | 4 / glass |
| Colour (w=white / lb=light blue / g=green / t=transpar. / tk=teak) |
| transp. | transp. |
| Shelf (on salad crisper) |
| YES / glass | YES / glass |
| Clip-on bottle rack |
| NO | NO |
| Wine rack nr. / type |
| NO | NO |
| Chiller area (0 to 3 ° C) |
| NO | NO |
| Pull-out tray |
| NO | NO |
| Crisper(s): |
|
|
|
| Number / colour | n° / - | 1/Tansparent | 1/Tansparent |
| Door: |
|
|
|
| Storage rack(s) (Total) | n° | 4 | 4 |
| Butter and cheese compartment |
| NO | NO |
| Inside colour |
| white | white |
| Reversible door |
| YES | YES |
| Lock |
| NO | NO |
| Self closure mechanism |
| NO | NO |
| Gasket colour |
| white | white |
| Freezer compartment |
|
|
|
| Drawer(s) | n° | NO | NO |
| Shelve(s) | n° | 1 | 1 |
| Flap(s) | n° | NO | NO |
| Soft fruit and ice tray | n° | 1 | 1 |
| Adjustable temperature drawer (ATD) |
| NO | NO |
| Colour of drawer (w=white, t=transp., g=green, gr=gray, b=blue) |
| NO | NO |
| Shelf in the Freezer | n° | 1 | 1 |
| Door rack(s) | n° | NO | NO |
| Accessories |
|
|
|
| Defrost water outlet |
| NO | NO |
| Interior light | W | 10 | 10 |
| Special ice maker |
| NO | NO |
| Ice cube tray(s) | n° | YES | YES |
| Eggs tray(s) / Total number of eggs |
| YES | YES |
| Adjustable feet (front / rear) | n° / n° | Y/N | Y/N |
| Castors (front / rear) | n° / n° | N/Y | N/Y |
| Wall spacer grid or distance holder |
| YES | YES |
| Flush back |
| NO | NO |
| Lenght of cable/incl. plug | cm | 180 | 180 |
| Packing dimensions & loadability |
|
|
|
| Packing dimensions ( H / W / D) | cm | 152X57.3X57.3 | 152X57.3X57.3 |
| Gross weight | kg | 60 | 60 |
| 40 ' Container load | pcs | / | / |
| 40 ' HC Container load | pcs | 140 | 140 |
| Logistic / recycling information |
|
|
|
| Packing weight | kg | 4.70 | 4.70 |
| Packing materials / Recycling symbols (RS) | RS |
|
|
| Carton | gr | 3200.00 | 3140.00 |
| Polystyrene (06) | gr | 1300.00 | 1300.00 |
| Polyethylene foil (04) | gr | 200.00 | 200.00 |
| Wood | kg | / | / |
| Service |
|
|
|
| Users instruction Manual (i. e. D / E / F / GB / I / NL / P) | Languages | E | E |
| Max. failure rate (during first 12 months) | % | 8.0 | 8.0 |
