Compressor Oil Purifier

Compressor Oil Purifier
Price: US $ 6000-8000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T
Prod Model: ZYT
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Working Vacuum: -0.06~-0.095MPa
Working Pressure: 0.4MPa
Water Content: 20ppm
Gas Content: 0.1%
Cleanness: Nas 6 Grade
Voltage: as Per User's Option
Folw Rate: as Per User's Option

Product Description

ZYT    ZANYO Vacuum turbine oil purifier
vacuum oil purifier is specially designed as oil filtration machine for
ZYT vacuum turbine oil purifier mainly be used for purifying unqualified turbine oil, especially for serious emulsion turbine oil, it can quickly and efficiently break emulsification, separate water, gas, particles from oil. So that makes sure quality of treated oil to achieve new oil's standard, ensure whole turbine system work safely. This equipment use a special polymer materials as filter medium combined with vacuum separating technology to break emulsification, dewater, degas, remove acid and particles, make the badly turbid turbine oil becomes clear transparent. Series ZYT is a perfect turbine oil purifier for live line work; also it can purify low viscosity hydraulic oil and lube oil.


Features:
1. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles
2. Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
3. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.
4. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
5. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
6. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
7. Work online with stream turbine, hydraulic turbine.

Technical Parameters:

Index NameUnitZYT -10ZYT -20ZYT -30ZYT -50ZYT -100ZYT -150ZYT -200ZYT-300
Flow rateL/Min10203050100150200300
Working vacuumMPa-0.06~-0.095
Working pressureMPa≤ 0.4
Temperature rangeºC20 ~80
Demulsifying valuemin≤ 15/min(GB/F7035)
Water contentppm≤ 20
Gas content%≤ 0.1
Cleanness
≤ NAS 6 grade
Power supply
380V 50HZ 3Ph (As per user's option)
Working noisedB(A)≤65~80

Chongqing Zanyo Electromechanical And Machinery Co., Ltd is located in Chongqing, China, the beautiful mountain city of. China. Chongqing city is called "the China filtration equipment & production base". ZANYO is a professional high-tech enterprise which insists on the specialized in the research, design, production, sale and service of oil filtration equipments for these years. Our new techniques for the "T" type evaporator and "S" type heater, thermal recovery system are very popular and we get very good feedback from customers. At the same time, we also design and provide the power equipments, oil testing equipments. Products are well sold at home and abroad and deeply favored by broad masses of clients!

To the company, we spare no effort to seek innovation and produce the stable performance, excellent products under the theory of "people-oriented, energy conservation, environmental protection, customer first, the benefit of future generations". Over the years, we win favorable comments in this circle of filtration. The leading products are transformer oil filtration machine, insulating oil purifier, lubricating oil purification system, hydraulic oil filter machine, turbine oil treatment machine, used motor oil recycling system and other industrial oil filtration machines. We also can provide the oil testers for our customers. The products are widely used in electric power, plant, mining, petroleum, chemical, metallurgy, waste disposal and other industries.

Since the establishment of the factory, we engaged in interior market for nearly ten year. From 2012, we exported the machines to foreign markets. We ZANYO factory always adhere to the basic principles: High quality machinery production.

Culture:

Our purpose: Quality first, Credibility first, Service first", to reach energy-saving emission reduction and win-win situation.

Our value: Users first, Brand success, Repay society

Our belief: Earnest, Innovation, Brave pursuit, Trustworthiness

Our dream: To endeavor to accomplish greater technological breakthrough; To endeavor to supply more environmental, more safely, and more efficient products and schemes; To endeavor to perform to the best and repay society.

Welcome domestic and international old and new customers to come to discuss business, to guidance, and we sincerely look forward to the parties and knowledgeable people work together to create brilliant!

Our products list as following:

ZYS-high effective vacuum transformer oil purification machine

ZYD-I, ZYD-II Double stages insulating oil purifier

ZYM-Mobile/trailer type transformer oil treatment equipment

ZYAD-Air dryer for drying electric equipments

ZYT-Turbine oil filtration machine

ZYJ-Coalescence and separating oil filter

ZYL-Lubricating oil purifier/hydraulic oil treatment device

ZYK- Phosphate ester fire-resistant oil purification machine

ZYR-Transformer oil regeneration device

ZYP-Plate pressure oil filter

ZYJL-Portable oil purifier

ZY-IIJ-II-BDV oil tester, insulating oil dielectric strength tester

ZYMMT-Oil moisture sensor, water content sensor

ZYRS-Engine oil regeneration system

ZYL-D- oil decoloring machine/oil recycling machine
