| Prod Model: |
KYRO-8000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Reverse Osmosis |
| Motive Force: |
Electric power |
| Usage: |
Water Treatment |
| Model: |
Kyro-8000 |
| RO Membrane: |
USA Dow |
| Pump: |
Cnp |
| Automation Degree: |
Automatic |
| Pretreatment: |
Fiber Glass |
| Power Supply: |
380V 50Hz 3 Phase |
| Sterilization: |
Ozone or UV |
| Certification: |
ISO9001/SGS |
| Application: |
Reverse Osmosis for Drinking/Industry |
Product Description
Certification Made in China 80 m3 /D Auto reverse osmosis water treatment ro water purifier reviews(8000L/H)
Model: RO-8000
Capacity of pure water: 8000 L/H 25degree
General power: 13.5KW
Electrical power: AC 380V 50Hz
RO membranes: BW30-400 Filmtec Dow 6PCS
Membrane housing: FRP
Multi-phases pump: (Nanfang or Grundfos optional)
Beforehand filter: Fiber glass and stainless steel optional
PP sediment membranes filter: 30" 5um
Booster pump: Nanfang, Hangzhou
Active carbon filter: 500kg
Quartz sand filter: 1800kg
Working process
Raw water----booster pump---quartz sand filter---activated carbon filter---water softener (optional)---security filter----high pressure pump---RO system----UV light---pure water tank(or bottled water filling production line)
Advantages:
1)System can produce water continuously and high degree automation.
2)No need chemical to regenerate, easy operation and maintenance.
3)Core components of RO system are imported USA DOW membranes.
4)Automatic switch on when low water level, and switch off when high water level
5)System flushes RO membranes automatically, reducing membranes polluted speed.
6)Water shortage protection for multi-stage pump
7)Product water conductivity meter can monitor water quality online continuously.
8)Low operation cost and long life span
9)There's RO controller, make whole RO system operating automatically.
10)Easily control and Maintained.
11)Auto membrane flushing
12)Environmental protection, Low power consumption
13) Auto flush/backwash
14) Low /high pressure protection
Because different water is of different quality. We will require for a raw water analysis or test report for inquiries of water treatment system. The reverse osmosis system is an ODM project for us as you know.
Application industry
1). Electronic industry: Pre-filter for ultra pure water, chemical products and pure water
2). Food and beverage industry: Filter for mineral water, wines and fruit juice
3). Medicine industry: Filter for drug liquid, gases
4). Chemical industry: Filter for organic solvent
5). Petroleum industry: Filter for oil-field flooding
After -sale service instructions
1)Warrantee: 1 year, all the components have problem within this year, will
Resend quickly for free.
2)User Manual: Provide the specific entire system"User Manual"
3)Spare parts: After 1year guarantee, offer spare parts with preferential
Price.
4)Technical guideline: Provide life long" Net Technical Support "freely.
5)Transportation: Offer professional shipping service/air service if necessary.
6)Documentary: Collecting cargo and handle paper work for exporting.
7)Order supervisor: Manage your order very well after planning stable orders to keep your stable market running.
Technical data for 8000L/H Reverse Osmosis System
| Technical specification for 8000L/H |
| Model | KYRO-8000 |
| Production capacity | 8000 L/Hr |
| Power | 13.5kw |
| Power supply | AC 380V 50Hz |
| Reverse osmosis (RO)membrane | Membrane BW30-400 8pcs USA DOW |
| Membrane housing | 4040 stainless steel |
| Raw water pump | CHL12-30 |
| Quartz sand filter, activated Carbon filter | φ1200×2300 FRP 2pcs |
| Security filter | 40 "× 5μm ,9core |
| High pressure pump | CDL12-16/11KW 1 set Nanfang |
| Activated carbon | 1800kg |
| Quartz sand | 500kg |
| Size (mm) | main machine: 2500X1300X2300mm |
| filtering tank:Φ1200×2300mm |
Guangzhou Kaiyuan Water Treatment Equipment Co., Ltd, are specialized in manufacturing reverse osmosis(RO) water treatment equipments. The RO system can purify tap water, underground water, river water and seawater to drinking pure water. Welcome your visiting to our factory warmly!
We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with the good quality at the reasonable price.
Our company has always insisted on relying quality to seek survival, benefit to seek development. Use fine after-sale service to meet the needs of consumers. Honesty and credit. Products are sold well all over our country. Warmly welcome all fields of friends to visit our company and negotiate trade.
We sincerely welcome new and old customers at home and abroad. Let us work together to develop the international market.
Welcome to order, we will serve you.
