| Prod Model: |
PM825 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Channel: |
8CH |
| Amplifier Output: |
2x325w |
| Warranty: |
Three Years |
| Certification: |
CE, RoHS |
| Application: |
Commercial |
| THD: |
0.005%-0.01% |
| Noise: |
<95dB |
Product Description
Power mixer
PM415 with USB for choice
~Power mixing console
~48Vphantom power
~2x7 band EQ
~Delay, L-R, G1-2, Trim, Pan, send effect
~2 group output and 100mm fader
~4 stereo output, 1 AUX return, 1 AUX send
~1 headphone monitor output with built in echo effector
~4 stereo input
~Each input channel with 3 band EQ
Model |
PM-415 |
PM-825 |
PM-1035 |
PM-1235 |
PM-1635 |
Channel MIC/Line |
4ch |
8ch |
10ch |
12ch |
16ch |
Line Channel |
4 stereo |
8 stereo |
10 stereo |
12 stereo |
16 stereo |
Channel EQ |
2 band |
3 band |
3 band |
3 band |
3 band |
Main Buses |
1 stereo |
1 stereo |
1 stereo |
1 stereo |
1 stereo |
Group Buses |
1 stereo |
1 stereo |
1 stereo |
1 stereo |
1 stereo |
Graphic EQ (MAIN) |
2x5 band |
2x7 band |
2x7 band |
2x7 band |
2x7 band |
Phantom Power |
+48V |
+48V |
+48V |
+48V |
+48V |
Effector |
ECHO |
ECHO |
ECHO |
ECHO |
ECHO |
Out Power |
4Ohm 2X150W |
4Ohm 2X325W |
4Ohm 2X325W |
4Ohm 2X325W |
4Ohm 2X325W |
Power Supply |
AC 120/240V/50-60Hz |
Dimensions |
43.00x37.00x28.00CM |
51.00x37.00x28.00CM |
56.00x37.00x28.00CM |
60.00x37.00x28.00CM |
65.00x37.00x28.00CM |
Gross Weight |
11.50KGS |
16.00KGS |
18.00KGS |
20.00KGS |
22.50KGS |
NAPHON MUSIC, based in Shenzhen, is a company specialized in the design and production of quality professional audio equipments. Its package of products are widely used in music venues, theatres, houses of worship, sporting events and much more.
NAPHON MUSIC has a major commitment to produce the most accurate & reliable product available. It maintains an extensive research and development division which is constantly looking for ways to improve the performance, value and reliability of products, introduced the Surface Mounting Technology, proudly launched its new MC series of DSP Mixers and SA series of Amplifiers. With a stringent quality control in production, it can arrive at an ever higher standard of quality for full range of products. NAPHON MUSIC had got ISO9001: 2000 International Standard Approval and CE approval.
NAPHON MUSIC always focus on tomorrow, embracing severe construction standards and the on-going aim to provide the best sound and most outstanding customer service you've ever experienced.
