4.3 Inch Resistive Touch Screen

4.3 Inch Resistive Touch Screen
Price: US $ 10-15/Piece
Trade Terms: FOB,CIF,FCA
Min Order: 1/Piece
Pay Type: T/T
Prod Model: 8940017082
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Active Area(Mm): 96.04*54.86
View Area(Mm): 96.04*54.86
Surface Hardness(Mm): ≥7h
Resolution Ratio: 480*272
Application: Security Monitoring System
Aspect Ratio: 16:9
Customized: Customized
Resistive Touch Screen Type: Digital
Screen Type: Capacitive
Screen Size: 4.3''

Product Description

Product Discription: 1. 4.3 inch resistive touch screen+TFT 2. High brightness Product Drawing: Product Parameter: Size:4.3"(2) Part number:8940017082 Lens size(mm):105.5*67.2*0.7 Sensor size(mm):103.5*65.2*0.7 Total thickness,without foam(mm):1.6 Active area(mm):96.04*54.86 Independent key:None View area(mm):96.04*54.86 Surface hardness(mm):≥7H Resolution ratio:480*272 Linearity(mm):±1.0(±1.5) Touch point:5 Working voltage:2.8-3.6V Interface I2C :1.VSS 2.VDD 3.SCL 4.NC 5.SDA 6.NC 7.RST 8.WAKE 9.INT 10.VSS Power (VDD=2.8V):Normal operation :6mA Monitor mode:4mA Sleep mode:0.03mA Transmittance(%):≥90 Haze value(%):<0.1 Operation temperature: -20°~70° Storage temperature: -30°~80° Product Advantages: 1. The type of touch panel can be customize. Capative and resistive screen are both available. 2. 4.3'' and 7'' TFT can be customize for high brightness back light. Visiable under the sun light. 3. Provide the CTP TOTAL SOLUTION, reduce the R&D time for customers.
Size: 4.3"(2)
Part number: 8940017082
Lens size(mm): 105.5*67.2*0.7
Sensor size(mm): 103.5*65.2*0.7
Total thickness,without foam(mm): 1.6
Active area(mm): 96.04*54.86
Independent key: None
View area(mm): 96.04*54.86
Surface hardness(mm): ≥7H
Resolution ratio: 480*272
Linearity(mm): ±1.0(±1.5)
Touch point: 5
Working voltage: 2.8-3.6V
Interface I2C : 1.VSS 2.VDD 3.SCL 4.NC 5.SDA 6.NC 7.RST 8.WAKE 9.INT 10.VSS
Power (VDD=2.8V): Normal operation :6mA Monitor mode:4mA Sleep mode:0.03mA
Transmittance(%): ≥90
Haze value(%): 0.1
Operation temperature:  -20°~70°
Storage temperature:  -30°~80°


Shenzhen Jinghua Displays Co., Ltd was established in 1987 as a professional LCD, LCM, Touch Panel and Cover Lens manufacturer. We also provide SMT / OEM / ODM services. Our strategic positioning is to be a professional supplier for human-machine interface. We have already become China National High-Tech Enterprise and the Vice President of China LCD Industry Association.

Innovation, High Quality, Trust, Environment Protection, Service, Safety, those are our Value orientation. Our customers are those enterprises who are looking for high quality, unique products, innovated technology and valued service. As we have stable finance status and excellent management group, a rich variety of new products, good service, and as we keep promises, follow environmental protection law, take social responsibility, we have a very good reputation. In this way, we have won praise from our customers all over the world.

We JHD have a stable design and development team for 30 years to provide our customers a completed ODM and OEM industrial product design and manufacture service. We can also provide a total solution service, from product concept, component structure design, mold making to embedded software custom developing and finished sample delivery. We keep developing new materials, searching new technology, pushing new products and applying for technology patent. Now we can provide a completed custom Human-machine interface solution, in automotive, Medical, industrial area, etc.

At our high-tech plants. Our advanced production, processing and on-line inspection systems are imported from Japan and the U. S. A. Monthly production capacity is in excess of four million LCD panels and modules.

We were certificated ISO9001 compliant by SGS in April 1997. We guarantee on-time delivery and excellent customer service to meet the demands of our clients. We will continue to place our main emphasis on technological innovation, product improvement and quality assurance.
