Prod Model: |
P7-S1 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
LCD Screen Size 3.0" LCD Touch Screen (H: |
Built-in Dual Camera |
Internal G-Sensor Car DVR: |
GPS Signal Receiver |
Touch-Sensitive Disply: |
Wide Angle Len |
Night Vision Car DVR: |
Hottest Car DVR Camera System |
Driving Video Recorder: |
Digital Video Camera Recorder DVR |
Balck Box Car DVR Dual Camera With GPS: |
Functional Car DVR |
Car DVR Built In Memory: |
Car Camera Recorder DVR HD 1080p |
Interface: |
BNC\VGA\HDIM |
Compression Format: |
H.264 |
Product Description
3.0 inch 19"9 High Definition Touch LCD Screen
High pixel with the Dual Camera Optional
Infrared Night Recorder Optional
1280*460(2CH Record)/ 640*480 (1 CH)
G-sensor Automatic locking videos
Support Recording GPS Tracker
Support Micro SD card ( up to 32G)
Automatic Circle Recording/ Motion Detect Function
Automatic segmentation video save covered
Els Anti-shake
Besides the common functions, four main characteristics have been added for the Tachograph as follows:
(1)It has internal dual lens, which makes it able to catch and shoot both front and back images.
(2)Touch-sensitive display (Button).
(3)GPS module has been added to it, which can record the complete driving/travel track. By using the special attached software, driving/travel track can be displayed on the map by connecting Google map through Internet while you can watch the video on the computer, which will help you to track the driving/travel track of the vehicle.
(4)It is equipped with internal Gravity Sensor (Gravity Sensor is short for G-Sensor). Gravity Sensor can record gravity sensing information and make judgments according to up and down, left and right, and front and back deviation of the vehicle, in case that the deviation approaches a certain value, it will be considered that abnormality occurred to the vehicle and it will automatically give lock protection to the current video. At the same time of viewing/watching the video on the computer by using the special attached software, you also can get the changes of gravity sensing data, which will help you to track the gravity status during the travelling course.
In order to bring the maximum function of the Tachograph into full play, please read this handbook before using (please understand that we will not give notice separately in case of any change to the design or specification of the Tachograph or its accessories).
Product Characteristics
- Ultra-small size, dual lens with high definition, it is a perfect combination that the back lens are able to rotate for 270 degrees and super-wide high resolution lens, which facilitate it, with more convenience, to shoot videos from multi-angles in various occasions to get the videos in high resolution.
- High definition of 3.0 inch LCD screen with touch function, icon touching operation, which is easier to be sensed and used.
- 1/4 inch internal photosensitive elements with low noise and high picture quality, which can capture ultra -clear pictures in relatively dark occasions
- Internal lithium polymer battery, which enables videos being shot while the battery is being charged.
- Internal microphone / speaker
- Support Micro TF card of high capacity
- It will be turned on and video shooting function will be started automatically as the vehicle starts
- It has delay starting function, which can prevent it from damage caused by transient pulse current occurred at the moment of vehicle starting
- GPS scanning and positioning, travelling track restoring, everything is under control.
- Infrared photosensitive
- Gravity Sensor for gravity sensing
- Video encryption protects user s' privacy by setting password
Accessories:
1. Vehicular Power; 2. Vehicular Bracket; 3. USB Cable;
4. Instruction Manual.
Technical Specifications as below:
LCD Screen Size |
3.0” LCD touch screen (High definition) |
Lens |
Dual-camera/lens(High definition), back lens has infrared night shooting function |
Language Options |
English/Simplified Chinese/Traditional Chinese/Japanese/Russian/German |
Video Format |
AVI |
TF Memory Card Slot |
Micro TF
|
Microphone / Speaker |
Internal located |
Vehicle Power DC Input |
5V 500MA |
Battery |
Internal lithium polymer battery |
System Requirements
|
Above/higher than Windows 2000/XP/Vista/Windows 7, MAC OS x 10.3.6
|
