| Prod Model: |
FIB-180WD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Daily Capacity: |
10000kg |
| Ice Type: |
Food Grade Ice Block |
| Ice Shape: |
Ice Block |
| Certification: |
CCC |
| Condition: |
New |
Product Description
Containerized Direct system Block Ice PlantFocusun research and develop the newest and high-tech direct refrigeration block ice machine (adopting aluminum alloy plate to freeze ice directly, there is no traditional brine tank or other auxiliary chemicals).
Comparing to traditional brine system block ice machine (with brine tank, with salt), direct refrigeration block ice machine has many advantages as follows:
1. Evaporator material: Direct refrigeration adopt aluminum alloy plate, brine system evaporator adopt stainless steel or galvanized plate material.
2. Main purpose: Direct refrigeration blocks ice used for human consumption, keep fresh, objects cooling. Brine system block ice can only be used for keep fresh, objects cooling.
3. Power consumption: Direct refrigeration block ice plant save electricity reaching 10% than brine system block ice plant.
4. Ice falling speed: Direct refrigeration block ice maker is 1.5times faster than brine system block ice maker, ice can fall off within 25-30 minutes.
5. Process of ice-doffing: Direct refrigeration only needs one person to operate, but brine system needs at least 3 people
6. Maintenance: Direct refrigeration can used forever, corrosion resistant, low maintenance. Brine system needs more maintenance.
7. Cost: Direct refrigeration price is a little higher than brine system.
With regards to block ice weight, we can design our standard weight ( block ice size: L X W X H mm) or customized.
5kg (120x100x460mm)
10kg (155x100x700mm)
15kg (185x125x700mm)
20kg (245x125x700mm)
25kg (315x125x700mm)
50kg (480x160x700mm)
Advantages of block ice making machine:
- Modular shape, featuring of plug-and-play ready system especially for tropical & costal environment design.
- Comparing to other types of ice, large block ice is very easy in storage, handling and transport.
- Block has the longest storage period comparing to other ice types.
- Machine dimension is designed strictly according to international standard size for the container, which is convenient for transportation.
If customers don't have an existing site to place the ice block machine, he or she can choose the block ice machine to be installed in a 20ft or 40ft container, for direct refrigeration block ice maker:
1) The smallest capacity containerized we make ice 6ton/day which in a 20' container.
2) The biggest capacity containerized we make is 18ton/day which in a 40' container.
For containerized block ice machine, it is very easy for transportation and installation, if you don't have suitable place to put the machine, we then recommend you containerized one, because you don't need to re-build a room again.
If you are interested in our products, please contact us. We would be very glad to be on service for you, as the most professional ice machine manufacture in China, we are pleased to attach our best offer. We are definitely to contact you within 3 days after getting your inquiry.
| Model | Capacity | Refrigerant | Total running power | Installation
Power | Operating weight | Dimension |
|---|
| -- | ton/24h | -- | kw | kw | kg | mm |
| FIB-05AD | 0.5 | R22/R404A | 2.055 | 2.5 | 560 | 1500×800×1800 |
| FIB-10AD | 1.0 | R22/R404A | 4.850 | 6.0 | 960 | 1800×1200×2000 |
| FIB-15AD | 1.5 | R22/R404A | 6.940 | 8.5 | 1260 | 2800×1200×2000 |
| FIB-20AD | 2.0 | R22/R404A | 8.160 | 10.0 | 1460 | 2800×1400×2000 |
| FIB-25AD | 2.5 | R22/R404A | 9.510 | 12.0 | 1660 | 3200×1400×2000 |
| FIB-30AD | 3.0 | R22/R404A | 11.520 | 14.0 | 2180 | 3600×1400×2200 |
| FIB-35AD | 3.5 | R22/R404A | 14.850 | 18.0 | 2100 | 3600×1650×2000 |
| FIB-50WD | 5.0 | R22/R404A | 20.950 | 25.0 | Unit: 960 | L1400×W1000×H1250 |
| Evaporator: 2860 | L4800×W1000×H2250 |
| Cooling Tower: 460 | 1380×H2170 |
| FIB-100WD | 10.0 | R22/R404A | 33.980 | 50.0 | Unit: 1680 | L1800×W1000×H1450 |
| Evaporator: 2860×2 | L4800×W1000×H2250 |
| Cooling Tower: 670 | 2000×H2410 |
| FIB-150WD | 15.0 | R22/R404A | 59.150 | 75.0 | Unit: 2160 | L2000×W1200×H1600 |
| Evaporator: 2860×3 | L4800×W1000×H2250 |
| Cooling Tower: 1120 | 2175×H2565 |
| FIB-200WD | 20.0 | R22/R404A | 85.550 | 105.0 | Unit: 2896 | L2400×W1600×H1800 |
| Evaporator: 2860×4 | L4800×W1000×H2250 |
| Cooling Tower: 1300 | 2650×H2645 |
| FIB-250WD | 25.0 | R22/R404A | 94.050 | 120.0 | Unit: 3260 | L3200×W1800×H2200 |
| Evaporator: 2860×5 | L4800×W1000×H2250 |
| Cooling Tower: 1630 | 3050×H2780 |
| FIB-300WD | 30.0 | R22/R404A | 113.550 | 150.0 | Unit: 3500 | L3000×W2000×H2200 |
| Evaporator: 2860×6 | L4800×W1000×H2250 |
| Cooling Tower: 2730 | 3300×H2785 |
Focusun listed some successful project of our block ice making machine, For your reference.
| Location | Project Owner | Focusun Products | Time |
|---|
| Germany | NOVOFERM INC. | Water Chiller+Block Ice Maker+Ice Storage Room | Jul.2009 |
| Oman | FIVE OCEAN GROUP | Big Capacity Block Ice Storage and Related Equipments | Aug.2011 |
| South Africa | SASOL SOUTH AFRICA | Block Ice Maker Machine+Water Chiller | Nov.2009 |
| Germany | BOSCH | Block Ice Maker System | Mar.2010 |
| India | FALSON ICE | Movable Ice Plant | Oct.2012 |
| Saudi Arabia | FLOWER ICE COMPANY | Evaporative Cooling Big Capacity Block Ice Plant | May.2012 |
| Congo | ACE IMPORT AND EXPORT Ltd | Direct Refrigeration Block Ice Plant | Feb.2010 |
| Iraq | BAKARR CORPORATION | Brine Big Capacity Ice Plant | Jan.2009 |
| Philippines | WESSL GENERALl TRAIDING | Ammonia System Block Ice Maker | Sep.2009 |
| Australia | ENGINEERING CONSTRUCTION COMPANY | Direct Refrigeration Block Ice Maker Machine | Dec.2010 |
| ^^ | ^^ | ^^ | ^^ |
Focusun Refrigeration is the most professional manufacturer in China, specialized in designing and manufacturing of high quality ice making machines, such as: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
Focusun is known across the country for our premium quality on the products we offer. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine's components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
