| Prod Model: |
HPA-1000-AC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Place Of Origin: |
Sichuan, China (Mainland) |
| Color: |
Gray White |
| Brand Name: |
CD Hop |
| After-Sales Service Provided: |
Overseas Third-Party Support Available |
| Weight: |
32kg |
| Noise: |
59dB |
| Airflow: |
3000-18000m3/H |
| Application: |
Cell Room Air Conditioner |
| Delivery Time: |
Around 20-30days After Confirmed The Order |
| Type: |
Cabinet Air Conditioner |
| Operating Voltage: |
230 VAC |
| Mounting: |
Wall/Window Mount |
| Certification: |
CE |
| Condition: |
New |
Product Description
Packaging & Delivery
| Packaging Details: | 1.Package Size: 592*325*861mm
Weight: 32kg
2.Daily safe package for battery cabinet air conditioner |
|---|
| Delivery Detail: | 30 days after confirmed the order |
|---|
1000w Outdoor Observation/duty/cell room air conditioning/conditioner
Technical Parameters
| Item | HPA300-AC | HPA600-AC | HPA1000-AC | HPA1500-AC | HPA2000-AC |
| Cooling Capacity(W) | 300 | 600 | 1000 | 1500 | 2000 |
| operating voltage | 220V~50HZ |
Noise
dB(A) | 63 | 63 | 63 | 63 | 63 |
| Working Temperature Ranger | -40ºC~55ºC |
| H(mm) | 500 | 750 | 1100 | 1100 | 1100 |
| W(mm) | 300 | 430 | 430 | 430 | 430 |
| D(mm) | 156 | 195 | 195 | 195 | 240 |
| Refrigerant | R134a |
| Inner IP | IP55 |
| L25- L35(ERR) | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 |
| L25- L43(ERR) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
Rated Power(W)
L25-L35 | 188 | 375 | 625 | 975 | 1250 |
Special Features
Energy Conservation and Environment Protection
Use international brand's high energy efficiency compressor
Use international brand's low-power centrifugal fan
Using environmentally friendly CFC-free refrigerant R134a
High energy efficiency ratio (EER) design
High volume of wind, small enthalpy difference, high sensible heat ratio design
Intelligent Control
Temperature sensor is external and can be pulled away
Temperature sensor calibration
Automatic starts when power up
Hydrogen fan control, applied to the compartment, periodically vent hydrogen battery release and
acid gas With access controlling, flooding, smoke detection, shock and tilt detection alarm, state
quantityaccess like temperature control equipment fault, alarms will be transmitted to the power
environment monitoring system via RS485 interface
High and low temperature thresholds setting and alarm detection
Fault alarm signal will be given when the system's key components like cooling or heating unit
fails, such as fan fault, compressor fault.
System will send alarm when temperature sensors malfunction and select air conditioner mode
according to the temperature inside and outside the cabin
Meet YD/T1363.3-2005 Communication station's power, air conditioning and environment
centralized monitoring and management system - Part III: front-end smart device protocol
Application Area
1. Equipment cabin of Mini ICT room
2. Equipment cabin of RRU outdoor cabinet
3. Equipment cabin of 4G base station outdoor cabinet
4. Equipment cabin of micro station outdoor cabinet
5. Electric power outdoor cabinet
6. Industrial control cabinet refrigerating
7. Laboratory dedicated refrigerating
8. Museum, wine cellar dedicated refrigeration
9. High luminance LCD/LED dedicated refrigerating
