Special features:
1. No need to remove original radio, just add this unit!
2. Three Zone function, listening to Radio/watching GPS image in the front and watching DVD/USB/SD/TV from the back Monitor synchronously
--------------------------------------------------------------------------------
For MERCEDES-BENZ C-class
* 6.95" digital 800*480 screen resolution
* Built-in GPS system
* Dual zone function (Listen Radio/CD while watching GPS image)
* Built-in Bluetooth
* USB port
* SD card slots (Two SD card slots, one for GPS, one for Multimedia)
* iPod control
* Built-in DVB-T tuner (optional)
* Built-in ISDB-T tuner (optional)
* Steering wheel control function (CAN-BUS built-in)
* Red button backlight
--------------------------------------------------------------------------------
The following maps of countries are available now:
EU MAP: Austria, Switzerland, Liechtenstein, Italy, Belgium, Netherlands, Luxemburg, France, Monaco, Spain, Germany, Greece, Vatican, San Marino, Denmark, Finland, Norway, Sweden, Portugal, Gibraltar, Channel Island, England, Ireland, Lisle of Man, Northern Ireland, Scotland
GULF AREA: Saudi Arabia, Oman, Bahrain, United Arad Emirate, Qatar, Kuwait
OTHER MAP: America, Canada, Australia, Turkey, Russia, Brazil, Argentina, South Africa, Chile are available
Menu Language& Navigation Voice: Arabic, English, Dutch, French, German, Italian, Portuguese, Spanish, Russia
|
GPS |
|
Operating System |
Windows CE 6.0 |
|
GPS Resolution Output |
800x480 |
|
Media Player |
Yes |
|
Card Supported |
Micro SD card |
|
MAX Memory Supported |
16GB |
|
Map Supported |
PolNav, Igo, Route66, Tom-Tom, Support 3D Maps |
|
GPS Baud Rate=9600, Com Port=2 |
|
Display Screen |
|
Screen Type |
Digital TFT touchscreen |
|
Resolution |
800*480 |
|
Screen Dimension |
6.95 inch 16:9 |
|
Language |
|
Main Interface Language |
English |
|
DVD Control Language |
English |
|
GPS Console Language |
English |
|
DVD Playback |
|
Disk Format Supported |
DVD/VCD/CD/MP3/MPEG4/CD-R/WMA/JPEG |
|
Media |
DVD/DVD-R/DVD+R/DVD-RW/DVD+RW/CD/CD-R/CD-RW/MP3/MP4(DIVX)/VCD/SVCD |
|
Bluetooth |
|
A2DP |
Yes |
|
Microphone |
Built-in |
|
Received Call |
Yes |
|
Dialled Call |
Yes |
|
Missed Call |
Yes |
|
Download Contacts |
No |
|
Store Contacts |
No |
|
TV Tuner |
|
Built-in Analog TV |
No |
|
Analog TV System |
/ |
|
Built-in DVB-T Tuner |
Optional |
|
DVB-T Format |
MPEG2 |
|
Built-in ISDB Tuner |
No |
|
Radio |
|
AM Frequency Range |
Support Original Radio |
|
FM Tuning Range |
Support Original Radio |
|
RDS |
Support Original Radio |
|
iPod Control |
|
Touchscreen Control |
Can Control Music Through Touchscreen |
|
Show Information Of Music |
No |
|
Play Video |
No |
|
Storage Media |
|
SD Card Slot For Music/Movie |
Micro SD card |
|
MAX Memory Supported 16GB |
|
USB Port For Music/Movie |
Mini USB Port |
|
MAX Memory Supported 16GB |
|
Position: Front Panel |
|
Portable HD |
No |
|
Video & Audio |
|
Video Input |
1-Channel RCA Input |
|
Video Output |
2-Channel RCA Output |
|
Audio Input |
2-Channel RCA Input |
|
Audio Output |
4-Channel RCA Output |
|
Reverse Camera Input |
Yes |
|
3 Zone Out |
No |
|
Other Functions |
|
2-Zone |
Yes (Listen Radio/CD While Watching GPS Image) |
|
3-Zone |
Yes (Listening To Radio/Watching GPS Image At The Front And Watching DVD/SD/USB/TV
From The Sub-monitor Simultaneously) |
|
Pictrue In Pictrue |
No |
|
Steering Wheel Control Function |
Yes |
|
CANBUS |
Yes |
|
MFD |
Yes |
|
TMC |
No |
|
V-6 Disc Changer Memory |
No |
|
CDC |
No |
|
Parking Assistance |
Yes |
|
Game |
No |
|
Button Back Light |
Green Illumination |
|
Accessories |
|
User Manual*1,Power Cable*1,Remote Control*1,iPod Control Wire*1, RCA Cable*1,GPS Antenna*1,Touchpen*1 |
