| Prod Model: |
FIM-series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Focusun |
| Usage: |
for Refrigerate |
| Power Supply: |
380V/3p/50Hz/ 220V/3p/60Hz |
| Control: |
Electric |
| Power: |
200W-400W |
| Structure: |
Integral Type |
| Material: |
Stainless Steel |
| Application: |
Household |
| Condensing Mode: |
Air-Cooled |
| Filtering Device: |
With Filtering Device |
| Automatic Cleaning Device: |
With Automatic Cleaning Device |
| Ice Shape: |
Flake Ice |
Product Description
Technical Data of Industrial Flake ice machine Model
Daily Capacity Bin Capacity Compressor Refrigerant Cooling Mode
FIM30K 3000kg 1, 200kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM40K 4000kg 2, 500kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM50K 5000kg 2, 500kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM80K 8000kg 4, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM100K 10, 000kg 4, 000kg Bizer/Hanbll R22/R404/R717 Water/Air Cooled
FIM150K 15, 000kg 6, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM200K 20, 000kg 12, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM250K 25, 000kg 12, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM300K 30, 000kg 16, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM400K 40, 000kg 16, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM450K 45, 000kg 20, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM500K 50, 000kg 22, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
FIM600K 60, 000kg 25, 000kg Bitzer/Hanbll R22/R404/R717 Water/Air Cooled
Before leaving the factory, every unit is tested to meet our high-demanded quality. Focusun provides the industrial flake ice machine with the capacity from 3, 000 kgs/24 hours to 60, 000 kgs/24 hours. Together with an evaporator, an insulated double-wall stationary cylinder is mounted in vertical position; And water is pumped into the top tray and distributed on the inner wall as a continuous water curtain. The low temperature refrigerant inside the cylinder walls makes the water freeze to the surface, and then the skate removes the ice from the wall without touching the cylinder. Because the ice is produced on the inner wall of the ice drum, the drum itself is static and only the water distribution and the skate are rotating. This allows the refrigeration system to be mounted in a rigid manner and stay completely sealed, which prevents the loss of refrigerant due to moving parts in the refrigeration system. Before leaving the factory, every unit is tested to meet the specifications.
Due to its internal structure and materials, our industrial flake ice machines for industrial use are reliable, corrosion resistant and high energy efficient. The ice flakes can reach the low temperature down to -6C-7C and up to 45C in tropical areas.
Perfect service system:
All Focusun ice machines come out with 15 months full warranty. If the machine breaks down in 15 months, Focusun will send the parts for free, even send the technician over if situation needed. When beyond the warranty, Focusun will supply the parts and service only for factory cost. |
Process: | Please provide the copy of Sales Contract and describe the problems appeared. |
| Problems confrimation: |
| Slight problem: | Please send the proof to our After-Sales Department, we will reply within two days. |
| Serious problem: |
|
| A | We will dispatch our Quality and Problems Appraisers to make a confirmation. |
| B | Have a negotiation of the compensation and sign agreements |
| C | Our After-Sales Department will perform the duties as the agreement |
Focusun Refrigeration is the most professional manufacturer in China, specialized in designing and manufacturing of high quality ice making machines, such as: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
Focusun is known across the country for our premium quality on the products we offer. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine's components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
