Spilt Solar Water Heater:
1. Inner water tank: SUS 304-2B food grade stainless steel
2. Outer water tank: Color steel
3. Bracket: Color steel /aluminum
4. Insulation layer: Polyurethane foamed 55-65mm
5. Vacuum tube: 58*1800/47*1500mm
6. Fasteners: Stainless steel screw
7. Sealing ring: Polymer silicone rubber
8. Reflective angle: 45° Golden angle
|
Spilt Solar Water Heater |
|
Evacuated tube |
Len(mm) |
1800mm |
|
Dia(mm) |
Φ 58 |
|
Quantity(pieces) |
24/36/48/60 |
|
Area(m 2 ) |
1.50/2.29/3.00/4.8m 2 |
|
Solar collector |
Heat Pipe |
Red copper TU2+water; transfer power: > =150W; Working pressure: 0.6Mpa |
|
Evacuated tube |
Borosilicate glass 3.3; Structure: Vacuum Degree: P< =5*10-4 |
|
Frame |
Aluminum Alloy, Thickness: 2.0mm |
|
Daily Efficiency |
> 65% |
|
Pressurized water tank |
Capacity |
200/300/400/500L |
|
Insulating Layer |
Polyurethane foaming, Thickness: 50mm |
|
Outer Shell of Tank |
Color Steel Plate(enamal white), Thickness: 0.4mm |
|
Inner tank |
SUS304, 2.0mm thickness |
|
copper coil (diameter*thickness*length)(mm*mm*m) |
|
200L |
300L |
400L |
500L |
|
Upper coil |
12*1*12 |
12*1*15 |
12*1*18 |
12*1*18 |
|
Lower coil |
12*1*15 |
12*1*18 |
12*1*24 |
12*1*24 |
|
Working station |
Circulation pump Brand: Wilo |
|
Controller |
|
Expansion vessel 8/12L |
