Product features:
Operation is simple, one button from the water, ice, ice, extrusion, thesnow ice, ice full automatic shutdown. The whole operation process is completed by the microcomputer control. The corresponding indicating lamp will be displayed, running lights, a refrigerator ice full indicator lightwill stop running.
Imported compressor, stable and reliable operation
The cavity of septum structure, making high energy efficiency, a large amount of ice
Full computer control, easy to operate
Ice storage tank using fluorine free polyurethane foam, insulation
Environmental protection refrigerant, R134A
Liquid crystal display will show all the above process (optional)
Equipped with voice prompt system (optional)
Optional colors, color experiment of your dreams
The whole system and the casing can be independently separated, convenient repair
Special safety design:
Automatic detection of skate is running on ice skates, prevent the death card;
External water indicator light will stop;
Automatic detection of the water inlet temperature, condensing temperature to adjust the production of ice;
Cut off the water supply shutdown and ice full stop, first close the bladerefrigeration system, continue their run off after 60 seconds, avoidimmediately start system skates have been frozen.
Specifications:
Models yield (Kg/24) input power (W) ice storage capacity (Kg) size(mm)
GYXH-85 8540035 580*610*900
Installation instructions for use:
Ice making machine may not be placed outdoor use in outdoor, avoid damp or easily water shower place
Ice making machine should be placed no corrosive gas, ventilation good location, the surrounding should have a distance about 200mm, ensure that the machine has good ventilation and heat dissipation
In the ice making machine should be adjusted to make the machine footsmooth, first should park 10 hours before boot operation.
The drainage tube should be less than the box body, facilitate the smooth drainage
Don't pull the temporary line, should be installed and fixed socket
Must be used to separate the three hole socket, and should have good grounding
Supply voltage should be used in the 190~240V
The use of ambient temperature at 5~35 dgree
The first food just for ice should not be used when the 8~10 minutes later, after eating the ice
When handling machine shall be not more than 45 ° Tilt, no inversion
Non professional repair personnel are not allowed to open the machinerepair without modification of the machine
