Resistive Touch Screen (UTL-4W15)
| Price: |
US $ 38.00 |
| Trade Terms: |
by air/by sea |
| Min Order: |
10/Piece |
| Prod Model: |
UTL-4W15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
15" |
| Connection Port: |
USB/RS232 |
| OS: |
Windows7, Windowsxp, Linux |
| Type: |
LCD |
| Application: |
Indoor |
| Screen Size: |
≤17" |
Product Description
Resistive touch panel is combined with 4 layers of visible complex film screen, the lowest layer is combined with glass or organic glass, the surface of top layer has past the induration process in order to make the plastic layer to be smooth and anti-scratch.
|
Outside Dimension |
247MM*322MM |
|
viewing area |
235MM*310MM |
|
Active area |
228MM*304MM |
|
Surface Hardness |
3H |
|
Optical Clarity |
80% |
|
Operating Temperature |
-10C ~60C |
|
Endurance Test strikes |
Over1million |
|
Operating Voltage |
DC5V |
|
Resistance |
200Ω~900Ω |
|
Linearity |
1.5% |
|
Film Thickness |
0.175mm, 0.188mm |
|
Glass Thickness |
0.7mm, 1.1mm,1.8mm |
|
Operation Pressure |
20~150g |
|
Storage Temperature |
-30 ~80 |
|
Message Noise |
5m sec ~ 15m sec |
|
Operating Current |
5mA~25mA |
|
Humidity |
<95% |
|
Isolation Resistance |
20MΩ DC25V |
|
Sealable against |
dust ,water, oil , static |
Since our foundation in 1999 and branded in "UTouch", Beijing IT01 Co., Ltd. Is a professional manufacturer focusing on researching and producing SAW (Surface acoustic wave) touch screen, touch monitor, touch kiosk and AD player (for building and car)with our own patent. We offer the largest selection of touch screen technologies, SAW touch screen, touch monitor and carefully design each product for the demanding requirements of diverse applications, such as industrial, medical, POS, kiosks, retail, hospitality, transportation, office automation, and gaming.
We are located in Beijing Zhongguancun High-tech Development zone, with such an advantageous technical and human resources, among the 20 R&D personnel, 95 percent have achieved a bachelor's degrees and even higher. Experienced electronic engineers and specialist technical personnel guarantee the technical services.
Up to now, we have expanded our product line with a series of new applications: Safe Touch, Dust proof, Kiosk Touch, Bevel Touch, and integrated touch monitors. We were granted ISO9001 and CE, FCC certifications. Our products had been sold to many countries all over the world such as Korea, Russia, Egypt, KSA, Ireland, Netherland.
Due to perfect cooperation with the customers from domestic and abroad, and hard working of all staffs, Beijing IT01 Co., Ltd has been growing by leaps and bounds. We would like to extend our warmest invitation to all overseas and mainland customers who want to pay a visit, provide suggestions or seek business co-operation.
