Qm91h R134A Refrigerator Compressor
| Price: |
US $ 1-100/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T |
WANSHENG R134a Refrigeration Compressor |
Test Conditions | H/MBP | Subcooling Temp.: 46.1°C |
| Evap. Temp.: 7.2°C | Cond. Temp.: 54.4°C |
| Amb. Temp.: 32.2°C | Suction Temp.: 35°C |
Model |
(-10°C )
Cooling Capacity
(W) |
(-5°C )
Cooling Capacity
(W) |
(0°C )
Cooling Capacity
(W) | (7.2°C)
Cooling Capacity
(W) | (7.2°C)Input Power(W) | (7.2°C )
COP Power Efficiency
COP (W/W) |
Motor Type |
Starting Device |
Starting Capacitor
(μF) |
Running Capacitor
(μF) |
Cooling Type |
| Power Supply 220~240V/50Hz |
| QM91H | 374 | 472 | 582 | 772 | 370 | 2.08 | RSIR | Starting Relay | / | / | F2 |
1. Small size
2. High efficiency
3. High reliability
4. Low sound
5. Light vibration
6. Use R134a refrigerant
7. R134a refrigerant system should strictly control the moisture, impurities, paraffin wax, such as silicone oil, and the content of chloride ion.
8. RSIR Motor
9. QM91H has passed CCC certification
10. H/MBP
11. Application in medium-large size refrigerator, freezer, cabinet, dehumidifier, liquor cabinet, etc.
12. Mainly used in commercial refrigeration
13. High cooling capacity under the different evap. Temp, details as the below separately table
14. Starting device is starting relay
15. Frequency only for 50HZ
16. Voltage application from 220 to 240V
| Prod Model: |
QM91H-5 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Piston |
| Performance: |
Low Noise |
| Drive Mode: |
Electric |
| Power Source: |
AC Power |
| Configuration: |
Stationary |
| Material: |
Copper |
| Piston Type: |
Closed |
| Lubrication Style: |
Lubricated |
| Application: |
High Back Pressure Type |
| Mute: |
Not Mute |
Founded in December 1994, Hangzhou Qianjiang Compressor Co., Ltd., is specialized in producing hermetic compressors for refrigerators, freezers and various household appliances. Due to attaching great importance to technical innovation and development of new products, the company owns a technical team to pursue the excellent and constant self-development.
