| Prod Model: |
P8 SMD 3in1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
320mm*160mm |
| Brightness: |
6200CD/M2 |
| Optimal Viewing Angle: |
160°(W) 120°(H) |
| Optimal Viewing Distance: |
8m~50m |
| Refresh: |
600Hz |
| Mean Time Between Failures: |
10000 Hours |
| Maximum Power Consumption: |
800W/M2 |
| Pixel Configuration: |
3 in 1 |
| Module Weight: |
0.55kg |
| Module Thickness: |
2.8cm |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
FCC |
Product Description
About Us:
Shengzhen Mountain A-Li Group Electronic Technology Co., LED. is a professional company manufacturing LED display system products for more than 10 years, established in 2000, covering a workshop area for 2000m2, with about 300 employees.
Products list:
| Item No.: | Description | Dimension | Brightness |
| | INDOOR | | |
| 1 | SMD indoor p3mm | 192mm*96mm | 2000cd/m2 |
| 2 | SMD indoor p4mm | 256mm*128mm | 2000cd/m2 |
| 3 | SMD indoor p5mm | 320mm*160mm | 2500cd/m2 |
| 4 | SMD indoor p6mm | 192mm*192mm | 3000cd/m2 |
| 5 | SMD indoor p7.62mm | 244mm*244mm | 2000cd/m2 |
| 6 | SMD indoor p10mm | 320mm*160mm | 3000cd/m2 |
| | OUTDOOR | | |
| 7 | DIP 3in1 outdoor P6 | 192*96mm | 7500cd/m2 |
| 8 | DIP 3in1 outdoor P7 | 224*112mm | 7500cd/m2 |
| 9 | DIP 3in1 outdoor P8 | 256*128mm | 8000cd/m2 |
| 10 | SMD 3in1 outdoor P6 | 192mm*192mm | 6000cd/m2 |
| 11 | SMD 3in1 outdoor P8 | 256mm*128mm | 6500cd/m2 |
| 12 | DIP 3in1 outdoor P10 round screen | 320*40mm | 8500cd/md |
| 13 | outdoor p10mm | 160mm*160mm | 8500cd/m2 |
| 14 | outdoor p12mm | 192mm*192mm | 7500cd/m2 |
| 15 | outdoor p13.33mm | 320mm*160mm | 5500cd/m2 |
| 16 | outdoor p16mm | 256mm*256mm | 7500cd/m2 |
| 17 | outdoor p20mm | 320mm*320mm | 7000cd/m2 |
Certificate:
Cases:
Advantage:
1. Low energy consumption,high brightness (brightness can be customized)
2. Low fault rate,long lifespan (2 more years lifespan than SMD board)
3. No color difference,large viewing angle (Horizontal 160°, Vertical 120°)
4. Optimal design,high-precision seamless,accurate to 0.1mm gap
5. Ultra-high refresh rate,can support video shooting,clear picture quality assurance
6. Quick and easy assembly,removing system,short loading time
7. Wide range of application
parameters:
| Item | Parameter |
| Product model | P8 SMD full color module |
| Module size | 320mm*160mm |
| Pixel pitch | 8mm |
| Pixel density | 15625dots/m2 |
| Pixel configuration | 3 in 1 |
| Module resolution | 32dots(W)*16dots(H) |
| Maximum power consumption | 25W |
| Module thickness | 2.8mm |
| Module weight | 0.55kg |
| Driving method | Constant current driving |
| Scan mode | 1/4 scan |
| Interface type | HUB75 |
| Brightness | ≥6200cd/m2 |
| The specifications of cabinet |
| Cabinet size | 640mm*640mm |
| Module quantity | 8pcs |
| Power supply | 5V/40A 5V/60A |
| Cabinet resolution | 96*96dots |
| Optimal viewing distance | 8m~50m |
| Optimal viewing angle | 160°(W) 120°(H) |
| Temperature | Storage:-35ºC~+85ºC
Working:-20ºC~+50ºC |
| System operating humility | 10%-95% |
| The specifications of power supply |
| Operating voltage | AC220V±10% |
| Average power consumption | 350W/H |
| Maximum power consumption | ≤800W/ |
| Current | ≤20mA(single LED) |
| The specifications of control system |
| Computer | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization control |
| The specifications of the main technical parameters |
| Driving device | Constant current driving |
| Refresh rate | ≥600Hz |
| Grey scale | RGB each 256 grade, can display 16.7M colors) |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
| Display mode | 800*600/1024*768/1280*900 |
HongKong Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.
Features:
1) With good lightening accordance and no mosaic
2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Applications:
LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
