P6 Indoor LED Display

P6 Indoor LED Display
Price: US $ 1000-1300/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Western Union
Prod Model: LS-I-P6
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brightness: 2, 000nits
Viewing Angle: 140/140 Degree
Color Temperature: 6, 500deg. K
Panel Size: 960X768
Resolution Per Panel: 128X96
Panel Material: Epoxy Paint Coated Cold Rolled Steel
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 6mm
Pixel Density: 27,777 dots / m²
Scanning Mode: 1/8 Scan
System Operating Platform: WIN XP
Display Type: LED Video Display
Application: Shopping Guide
IP Rating: IP40
Certification: RoHS
Pixel Configuration: 3 in 1 SMD

Product Description

p6 Indoor LED Display

Features:
*Competitive prices;
*High brightness & High resolution;
*High contrast ratio which ensures vivid images;
*Low power consumption, environmentally friendly;
*Wide viewing angle, 140 degree both horizontal and vertical;
*Customizable for various sizes;
*Compatible software: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA;
*Excellent after-sales service.



ParameterUnitValue
Pitchmm6
Brightnessnits2, 000
Color temperaturedeg. K6, 500
Viewing angle  Horizontal (50% brightness)deg.140(-70 ~ +70)
Viewing angle  Vertical (50% brightness)deg.140(-70 ~ +70)
Panel weightkg26
Panel diagonalmm960
Panel widthmm768
Panel heightmm576
Panel depthmm150
Panel areasq. m.0.442
Panel material
Epoxy paint coated Cold rolled steel
Operating temperature rangedeg. C-30 to +60
Humidity operatingRH10% ~ 90%
Pixel type and configurationR/G/B3in1 SMD
Resolution per panel
128x96
Dot per panel
12, 288
Dot per sq. meter
27, 778
LED per sq. meter
27, 778
Recommended minimum viewing distancem6
Recommended best viewing distancem8~20
Colors
281 Trillion
Grey scale (linear)Levels65536 levels
Brightness controlLevels256
Contrast ratio
1, 000: 1
Processing depthbit14
Video frame rateHertz60
Display refresh rateHertz600
Input voltage (nominal)VAC110 to 240
Input power frequencyHertz50 to 60
Input power (max)Watts / sq. m.760
Input power (typical)Watts / sq. m.304
Lifetime (50% brightness)Hours≥ 100, 000
Red wavelength (dominant)nm620~625
Green wavelength (dominant)nm520~525
Blue wavelength (dominant)nm470~475
Panel input format
DVI
Data interconnection
UTP Cat 5/Optical Fiber
Mounting system
Fixed with 4pcs M10 bolts

LEDSOLUTION is a competitive Global supplier Of LED Video Displays, LED Lighting and LED Components Solutions. We are specialized in High quality LED products including research, development, Production and marketing, serving various turnkey Solutions for government projects, corporate image Projects, commercial projects, and release of network Information, etc.

With the number of more than 300 staff, including our Research and Development staff which is a team of Over 80 members, and an accumulation of eight year Experience in the industry, LEDSOLUTION has become One of the world' S leading LED application Manufacturers. We owms totally 5, 000m2 super clean and antistatic workshop as manufacture base in Shenzhen. We have the whole set of international advanced Automatic machines and quipments, including advanced manufacturing equipments and perfect testing devices. We have already passed Switzerland quality system SGS ISO 9001: 2008 and ISO 14001: 2004 environment System certificate, RoHS test, CE certificate, CCC, ETL And other quality certificates, IP67 waterproof and dustproof test, EMC test, high and low temperature, heavy metal test. In May 2008, LEDSOLUTION was rewarded as "2007 China Excellent Company in LED Industry" by three top class national associations and media. In May 2009, LEDSOLUTION was titled the Most Promising LEDEnterprise in China for the Year of 2008 and was Granted the Excellence Award for LED Application In China for the Year of 2008 by China Electronics News, China Optics and Optoelectronics Manufactures Association (COEMA) and COEMA of LED Display Application.

For many years, relying on acuminous market awareness and in line with the enterprise spirit of Diligence, solidarity, innovation, transcendence and the goal of pursuing high technology, high quality

And high benefit, we have made big progress in High Tech field and now possess our own brands And independent intellectual properties. We have established completed market network and after Sales service network in domestic and overseas markets. In China, with 16 branches, LEDSOLUTION has owned very mature network of sales and after service. Our domestic customers are positioned at Top 500 enterprises in the world, such as Bank of China, China Mobile, China Safety Insurance, etc...Our products have been exported to all over the world, such as North America, Europe, SouthAmerica, Middle East Area and Southeast of Asia etc...
