| Prod Model: |
P20 DIP outdoor display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: |
320mm*160mm |
| Brightness: |
≥7000CD/M² |
| Mtbf: |
≥9000hours |
| Control Card: |
Linsn/Nowa |
| Lifespan: |
≥100000hours |
| Control Mode: |
Synchronization |
| Operate System: |
Win98/2000/Nt/XP |
| Delivery: |
10-20 Working Days After Reveived Payment |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
20mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
300W / m² |
| Scanning Mode: |
Static Scan |
| Display Type: |
LED Video Display |
| Certification: |
FCC,IP65 |
| Pixel Density: |
2500dots/M² |
| Application: |
Stage Performance,Advertising,Shopping Guide |
Product Description
| Item | Parameter |
| Model | P20 full color LED module |
| Module size | 320mm * 160mm |
| Pixel pitch | 20mm |
| Pixel density | 2500dots/m² |
| Pixel configuration | 1R1G1B |
| Module resolution | 16dots(W) * 8dots(H) |
| Driving method | Constant current driving |
| Scan method | Static scanning |
| Interface way | HU40 |
| Brightness | ≥7000cd/m² |
| Cabinet size | 960mm * 960mm |
| Power supply mode | 5V/40A 5V/60A |
| Optimal viewing distance | 20M - 50M |
| Optimal viewing angle | 160º(W) 120º(H) |
| Environment temperature | -20º ~ +50º |
| Relative humidity | 10% - 95% |
| Operating voltage | AC220V ± 10% |
| Average power | 300W/H |
| Max power consumption | ≤600W/m² |
| Control mode | Synchronization with PC |
| Driving device | IC constant current driving |
| Refresh rate | ≥600HZ |
| Gray/Color | RGB each 256 grade,can display 16.7M color |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
Product Features.
1. High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing
the strong sunshine directly.
2. Weatherproof design, completely outdoor use.
3. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.
4. Easy for assembling and connection with the connector added.
5. High color uniformity and clear image can bring you a vivid audio visual effect.
6. Both front and rear access are available.
7. Use the same level of red, green and blue led chips, which makes the image display of whole led display
more excellent and uniform.
Using range.
Widely used in a variety of needs large hall, sports arena,banking, telecommunications, government agencies, terminal, pier, railway stations, the stock market and other trading market, medical systems, electric power, galleries and other publicity, advertising, information dissemination, the guide places.
Service.
1. We guarantee all our display,modules for two years.
2. We provide technology training for free, which contains the operation and maintenance
training of the LED screen in the factory.
3. After sales,if have any problem about our products,you can inform us by E-mail,
we will reply you at once when we get it and will offer you a good solution to solve the problem.
Installation.
1. we can assist the training and technical support for customer in factory if need.
2. We can send our engineer to guide the installation for you,but the relevant cost should be paid
by your company.
3. Our technicians will offer CAD drawing to show how to install the LED display.
Delivery.
1. 10-20 working days after receiving deposit.
2. Before delivery,we will test the display and keep it light up for 72 hours at least.
Trade term: FOB Shenzhen,China.
Paymet term: T/T 30% deposit before production,the balance before delivery.
Packaging: Wooden case or flight case.
Shipping freight are quoted according to your requests.
HongKong Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.
Features:
1) With good lightening accordance and no mosaic
2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Applications:
LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
