Technical specifications:
1 Specification: 2m*1m*70mm/80mm/90mm; 2m*1.5m*70mm/60mm/90mm
2 Material of core: Copper and aluminum unfied core, heat pipe diameter: 22mm/25mm. Few welding line, high intension, and strong pressure resistance.
3 Coating: Anode oxidation film
4 Tempered glass: High transmittance, good heat preservation, firm and long service life, thickness is 4mm or 5mm.
5 Work pressure: 0 Mpa
6 Aluminum alloy profile: Electrophoresis aluminum alloy profile treatment, beautiful outlook and more high anticorrosion.
7 Special preservation: Glass wool/ high dense polyurethane foam
Less heat loss, more efficiency and more beautiful
| Flat Plate | Spec. (mm) | 2000*1060*70 2000*1060*80 2000*1060*90 |
| Solar Collector | Cover Glass | Tempered/ Tempered woven / tempered low-iron woven glass |
| Coating | Selective / Black Chrome |
| Core | All red copper core & pipes |
| Insulation | Glass wool + benzene plate/ Glass wool + polyurethane foam |
| Water tank | Capacity | 100L/ 120L/ 150L/ 200L/ 250L/ 300L/ 400L/ 500L |
| Inner tank | Food-grade stainless steel SUS304-2B |
| Copper coil | All red copper Φ 12 X 1.0mm |
| Insulation | Imported polyurethane integrated foam-forming 50mm |
| Tank shell | Color steel plate / Stainless steel |
| Bracket | Spec. (mm) | 1.2 ~ 1.5mm in thickness |
| Material | Hot-dip galvanized steel / Stainless steel / Aluminium alloy |
| Accessories | Workstation, Electrical heater, Magnesium rods, T& P valve |
| Pressure | 7 bar |
| Tilt angle | 0° ~ 90° |
| Water output | 45~95 o C |
Haining Qiruite Photoelectric Co., Ltd. was founded in 2001 and specialized in producing of solar water heaters(mainly), solar lights. In addition, we also have the capacity of researching, developing, designing, manufacturing and installing large scale solar-heat-collector projects and its central-control system. Our factory covers an area of 28, 000 square meters and has an annual production capacity of 100, 000 solar water heaters.
We trust product quality is our life. Therefore, we have got the certificates of Solar keymark, CE, ISO9001: 2000 and CCC. Our production line include over fifty working procedures, and we manipulate strictly under the measure requirements and working order. Our products are exported to many countries with good honor, such as EU, North America, Middle East, South Africa, Southeast Asia and etc.
We can guarantee high product quality. According to different individual requirements such as area, climate and consumption level, more and more productions come into the market from Qiruire. All our successes are based on the research and analysis of the market. If you are interested in any of our products, please feel free to contact us without hesitation. and we are looking forward to having opportunities to become your future honor supplier.
