| Prod Model: |
DJL-QFL |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| High Freezing Efficiency: |
Low Freezing Cost, Very Security |
| Temperature Control: |
Computer Thermostat |
| Temperature Type: |
Double-temperature |
| Defrost Type: |
Frost-Free |
| Function: |
Freezing |
| Certification: |
ISO |
| Capacity: |
500kg/H~2000kg/H |
| Door Number: |
No Door |
| Type: |
for Aquatic Products,Meat,Fruits Quick-Freezing |
| Door Type: |
No Door |
| Power Source: |
Electricity and Liquid Nitrogen |
Product Description
| Type(tunnel type) | Tunnel length(mm) | Band width(mm) | Power(KW) | Frozen output(kg/h) |
| DJL-QFL500A | 6000 | 800 | 10 | 500 |
| DJL-QFL1000A | 9000 | 1000 | 19 | 1000 |
| DJL-QFL1500A | 12000 | 1200 | 24 | 1500 |
| DJL-QFL2000A | 12000 | 1200 | 29 | 2000 |
Applicable to flow-line production of high value-added products, such as processing of fish&shrimp, shrimp meat, seafood, freshwater fish, meat product, high grade fruits and medical materials, etc.
Equipment material: the internal and external parts are mande of SUS304 stainless steel, which is durable and corrosion resistance.
Distribution specification:380v/50hz working temperature:-150ºC-room temperature
Cooling rate:≥20ºC/min temperature control precision:±2ºC
it applys to continuous large-scale industrial production pattern with flexible manpower and large area; it can be combined with other food lines into automatic line.
Established in 2001 and located at Guangming District, Shenzhen, Shenzhen Dejieli Refrigeration Technology Co., Ltd. Is a new high-tech enterprise with the integration of R & D, production and sales, and passed the ISO9001 Management System Certification in 2010. The company is mainly engaged in the R & D, manufacturing and sales of liquid nitrogen refrigeration equipment. Meanwhile, we also provide the total solution of ultra-low refrigeration and quick-freezing technology for customers.
The Dejieli series products adopt the latest liquid nitrogen refrigeration technology, temperature control technology as well as the technology of heat conduction & heat preservation, and match the compressor refrigeration, air cooling and liquid cooling as per various conditions and requirements of customers to reduce the cost and meet the quick-freezing requirements of customers.
Our products are of many types and specifications, such as the tank type, cabinet type and tunnel type, etc. Meanwhile, the personalized products can be designed and manufactured as per requirements of customers. These series products have been widely used in many domestic and foreign areas, such as the food processing, mechanical engineering, genetic engineering, precision electronic, medical research, plant conservation, aerospace and rear livestock, etc.
Maintain better quality of your food with our instant refrigeration skills!
Enterprise vision: Make the food and life better.
