Main Features
- Full PC Function
-10.2" Digital TFT Widescreen Display
-VIA C7-M 1600MHz, 512 MB/1GB DDR, 80G/120G HDD
- Support Windows XP Operation System
- Building Stereo Speakers
- Full Function Keyboard
- Internet Connect Port & Built in WiFi
- USB Port & SD/MMC Extend Storage Slot
- Internal Big Volumn Li-polymer Battery
- Support external GPRS, WiFi, GPS dongle
| Brand | AMANO |
| Customer model No. | |
| Safety and regulation | CE,FCC,UL |
| AC cord | as requested |
| | |
| Display Features |
| Display Technology | TFT Digital LCD Display |
| Screen | 10.2”wide screen |
| Resolution | 1024×600 WXGA |
| | |
| | |
| | |
| | |
| Hardware |
| CPU | VIA C7-M 1600MHz |
| DDR | 512MB, maximum 1GMB |
| HDD | 2.5" 80GB HDD maximum 120GB . |
| Extend Storage | SD/MMC Card, up to 4GB |
| Keyboard | Standard Mini Keyboard(82KEY) |
| Touchpad | yes |
| Build in WIFii | 802.11B,G |
| Ethernet module | 10/100Base-TX . |
| Web camera | Build in |
| Software |
| Operation System | Support Windows2000,Windows XP |
| Microsoft Office | optional |
| Internet Explorer | optional |
| Windows Media Player | optional |
| Others | as requested |
| Audio |
| Built-in Stereo Speakers | Yes |
| Built-in MIC | yes |
| | |
| Terminals |
| Power Input | 1, (18.5V 3.5A) |
| VGA output | 1 |
| Standard USB Port | 3 |
| SD/MMC Card Reader | 1 |
| Network Connect (RJ45) | 1 |
| Earphone Output | 1 |
| MIC input | 1 |
| Accessories |
| Rechargeable Battery | 3CELL-2200MAH / 6CELL-4400MAH (OPTIONAL) |
| AC/DC Power Adapter | 1 |
| Guide Manual | 1 |
| Driver Disc | 1 |
| | |
| | |
| Power supply | Adapter (100-240V ~ 50-60 Hz 1.7A 18.5V 3.5A) |
|
| Shipping Details |
| Dimension (WxDxH)-Unit | 257mm×195mm×33mm |
| -Giftbox | 285X225X105mm |
| - Carton | 585*540*535mm |
| Weight-Net | 1.3kg (including battery) |
| -Giftbox | 1.87kg |
| -Carton | |
| 20’’/40’’/40’’HQ Loading: | 1650 /3430 |
Established in 2004, Aimson has been one of the first pioneers in the consumption Field in Shenzen of China who has been capable of applying consumption Technology based products into the various Vertical Market needs like Mobiles, MP3/4/5 Players, USB Sticks, different kinds of Memory Cards, Digital Photo Frame, All-in-one TV PCS, Laptop and Embedded products (IPC).
With years of experiences in the Vertical product field, we have realized that the most profitable business focus of our business partners in the Vertical System Integration Market, the so called Vertical System Integrators or VSI Distributors value the most on their Project based businesses, in order to fulfill this needs, our entire team has been tuned up to address our main efforts on the unique business model "PACTS" which leads us further to our slogan_"Customized Solutions with PASSION".
The Business Model "PACTS"--
1) Passionate Flexibility
2) A+ Accuracy
3) Competitive Customization
4) Time-to-market
5) Satisfactory Solutions
The Three Principles:
The whole company's focus is running by the "PACTS" business model, with the motivation of the three principles, "Value-Added", "Differentiated Value-Add" & "Customized", these three principles go for the way we see our vendors, the way we act and the way how we work with our business partners, we always think about how we should apply these three principles into our daily interaction/cooperation with our Vendors & business Partners, we know the fact is, if we can create the Value-Add, Differentiated Value-Add or even better the Customized Differentiated Value-Add, then
The chance for all parties to stay in the food chain for the long run is more secured.
The Consistent Quality:
We know that the Quality should be designed-in right from the very beginning and must be carried out with long term commitment to ensure its consistency can be stabilized.
