Kitchen Cube Ice Making Machine
Specifications
1. Customized design
2. High efficiency output
3. High quality components
4. Responsible and professional service
5. Block ice
Product Analysis:
1. Default Voltage: 380V-3P-50Hz, also can according to customer's special requirement.
2. Applicable for fresh water, Refrigerants is R404A/ R22.
3. Thickness of flake ice: 1.5~ 2.2mm.
4. Applicable working condition: Ambient Temp.: 0~55 ° C, Water Temp.: -2~ 45° C
5. Standard working condition: Ambient Temp.: 25° C, Water Temp.: 18° C, Evaporating Temp.: -20° C.
6. Daily output: 1000kgs/24h
7. Total Power: 4.4KW
8. Cooling Type: Air cooling
Design/ Technology/ Material:
1. PLC control system ensure stable running, high efficeincy and simple maintenance.
2. Our evaporators are made up of stainless steel SUS304 or carbon steel, ensure longer life time
3. Evaporator shaped with one time abscission molding which can avoided false welding
Very well.
4. Energy and Environmental Welding Technology can up to Europe Alliance's strict requirement for
Ice making machine in energy and environmental standard area, and improved the ice production.
5. We use advanced electric heating oven to eliminate Thermal Stress Of Steel.
6. Auto Fault Alarm Function.
| Model | Capacity
(kg/24h) | Storage
(kg) | Refrigerant | Voltage/Frequency
(V/Hz) | Power
(W) | Cooling Type | Unit Size
(WxDxH,mm) |
| ZBJ-35PA | 35 | 20 | R134a | 220/50,60 or 115/60 | 440 | Air/Water | 510x585x750 |
| ZBJ-40PA | 40 | 25 | R404A | 220/50,60 or 115/60 | 490 | Air/Water | 510x585x895 |
| ZBJ-60PA | 60 | 35 | R404a | 220/50,60 or 115/60 | 550 | Air/Water | 680x585x895 |
| ZBJ-80PA | 80 | 35 | R404A | 220/50,60 or 115/60 | 665 | Air/Water | 680x585x895 |
Application:
Supermarket preservation, seafood restaurant, food processing, fruit and vegetable preservation, etc.
Certificate:
National patent(for some of our technology), SGS, CE, ISO14001, ISO9001.
Jiangmen Pukui Intelligent Machine Co., Ltd, is one Subsidiary Company of FuShi Group, have become a rather strength manufacture enterprise in drinking water treatment equipment since established. We run with ourselves independent innovation and ourselves specific features way. It is main to research and manufacture intelligent water treatment equipment, and have formed water vending machine as core of multiple intelligent vending equipment.
We are the more early manufacturer to research and manufacture the auto vending machines with induction and with paper money to sell, and is one more early enterprise of purifying water ( water station )equipments (main products including: Water vending machine, RO water treatment, integrative beverage package, 3/5 gallons auto bottling machine, home water treatment equipment, Piping drinking pure water equipment and many related equipment), made big contribution for the pure water market development and the promotion and popularization of piping drinking water
We are high-tech Co., professional in researching, manufacturing and selling in field of RO water treatment equipment, auto vending equipment, filling equipment. We strictly manufacture and manage according to ISO9001: 2000 System, and follow national standards and the related standards of World Health Organization. We can provide the best service for customers.
We will continue researching, developing and innovating to manufacture high quality products to satisfy different customers need, continue improving the drinking water level for people. Our company final target is to improve drinking water quality.
And we sincerely welcome customers all over the world to visit our company, or browse, visit our website. Any requirement, please contact us by E-mail, telephone or fax, we will provide best service for customers.
