| Prod Model: |
SZTP1200-8.4 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
High Quality Touch Screen 8.4 Inch |
| Size: |
8.4" Inch |
| Structure: |
Film + Glass |
| Connector: |
Pin 4 Plug Connector |
| Thickness: |
1.4 ± 0.15 mm |
| Touch Media: |
Finger, Touch Pen, Glove |
| Type: |
4 Wire Restistive Touch Screen |
| Ratio: |
4:3 |
| Resolution: |
4096*4096 |
| Aspect Ratio: |
4:3 |
| Application: |
Security Monitoring System |
| Screen Type: |
Resistive |
| Resistive Touch Screen Type: |
Analog |
| Screen Size: |
8.4''inch |
| Customized: |
Custom Service Available |
Product Description
Product Descreption The Feathers Of High Quality Touch Screen 8.4 Inch As Bellow: 1.High accuracy and sensitivity.
2.Operable in various light condition.
3.Adapt to adverse environmental conditions such as liquid splashes and wash down.
4.It met CE,ROHS certification.
| Size | 8.4" inch |
| Structure | Film + Glass |
| Connector | Pin 4 plug connector |
| Thickness | 1.4 ± 0.15 mm |
| Touch Media | Finger, Touch Pen, Glove |
| Type | 4 Wire Restistive Touch screen |
| Ratio | 4:3 |
| Resolution | 4096*4096 |
| Response Time | ≤ 10 ms |
| Supply Voltage | 5V DC; 35 mA |
| Transparent | ≤ 78% |
| Screen Resistance | X:100-500Ω Y:200-1000Ω |
| Insulation Resistance | ≥20MΩ(10V DC) |
| Pressure | 30-150g |
| Surface Hardness | 3H |
| Life Span | > 1,000,000 time knocking ;
≥ 100,000 time in paddling |
| Operating Temperature | - 10ºC ~ +60ºC |
| Storage Temperature | - 20ºC ~ +70ºC |
| Storage Humidity | 20 ~ 85% RH (except congeal fog) |
| Custom Service | Available |
The Packing & Delivery of High Quality Touch Screen 8.4 Inch:Packing: Anti-Static Foam+Paper Card+Ragged Bag+Carton
Delivery:5 work days after your finish paymentPayment Terms of High Quality Touch Screen 8.4 Inch:- Full payment before delivery.
- Prepay 30% as the deposite,T/T 70% the balance before delivery.
- Prepay 50% as the deposite and mould fee ,T/T the balance before delivery.
- Payment method can be nogotiated.
About Warranty: 1 Year without damaged by people actions.
About Our CompanySHENZHEN CKINGWAY TECHNOLOGY CO., LTD GUANGDONG, CHINA(MAINLAND) ACCOUNT REGISTERED IN 2013 BUSINESS TYPE: MANUFACTURE, TRADING COMPANY
Website:www.ckingway.comThe FAQ of High Quality Touch Screen 8.4 Inch:
1.Why Choose Ckingway?
1)Enough industrail experience and involved main markets all over the world.
2)Dedicated and professional sales team will offer you 24 hours online and immediate service.
3)Precise and advanced equipments.
4)High quality and sensitivity.
5)Many kinds of products with all size.
2. What can we do for you:
Custom service is available.
3.What is the lead time of the products?
Samples in stock will be sent within 3 days after payment.
Two to Four weeks for mass production.
4.Payment methods?
T/T and Western union etc.The details of our payment terms is showing above.
5.How long is the warranty period?
About Warranty: Usually 1 Year without damaged by people actions. It depends on different products.
6.What is the products application?
Widely used in instrument, handheld devices, industrial control, medical, automotive, smart home and other fields.
