High Quality Box Type Copeland Scroll Compressor Condensing Unit with Controller
| Price: |
US $ 430-500/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
SLP |
| Markets: |
North America,South America,Eastern Europe,Africa,Eastern Asia |
| Air Volume: |
1080 |
| Frequency(Hz): |
50/60 |
| Net Wieght(Kg): |
120 |
| Brand: |
Shenglin |
| Frame Material: |
Galvanized Steel |
| Place Of Origin: |
Shanghai, China (Mainla |
| Cooling Capacity: |
20kw-100kw |
| Room Temperature: |
-10 to 5 Degree |
| Compressor: |
Scroll Compressor |
| Compressor Brand: |
Copeland, Bitzer |
| Condensation Forms: |
Air-Cooled |
| Refrigerant: |
CF2Cl2 |
| Type: |
Steam Condenser |
| Certification: |
CCC |
| Condition: |
New |
Product Description
Feature:
1.Danfoss Maneuop hermetically sealed refrigeration compressor, large internal free volume, able to effectively prevent liquid strike;
2.Aluminum condenser with copper tube, efficient heat exchanger, and long service life;
3.The domestically produced high-quality refrigeration parts, units equipped with receiver, filter, solenoid valve, pressure controller, high and low voltage meter, and junction box.
Our Advantages:
1) Professional manufacturer, ROHS, BV, SGS,
2) More than 15 years' experiences of manufacturing. Cooperate with many famous brands: Midea , Gree, TCL, LG, Samsung, Hitachi, Panasonic etc.
3) Experienced technical staff. We have senior engineers and technicians more than 20 people with many years of experiences.
4)Our products can be customized. We can produce for clients according to the sample or drawings.
| Unit Model | Compressor Model | Power | Refrigerating capacity | Tube
specification | Overall dimensions
(mm) | Mounting dimensions (mm) | | KW(KW) | W | Muffler | Liquid tube | A | B | C | a | b | | MGH(Z)-28 | MT(Z)28 | 2.2 | 4700 | Φ12 | Φ10 | 680 | 610 | 570 | 570 | 400 | | MGH(Z)-36 | MT(Z)36 | 2.95 | 6010 | Φ16 | Φ10 | 960 | 680 | 470 | 910 | 370 | | MGH(Z)-40 | MT(Z)40 | 3.34 | 6610 | Φ22 | Φ12 | 960 | 680 | 520 | 910 | 370 | | MGH(Z)-50 | MT(Z)50 | 3.8 | 7400 | Φ22 | Φ12 | 1060 | 680 | 730 | 1025 | 400 | | MGH(Z)-64 | MT(Z)64 | 4.86 | 9780 | Φ22 | Φ12 | 1300 | 750 | 770 | 1250 | 420 | | MGH(Z)-80 | MT(Z)80 | 6.0 | 12380 | Φ28 | Φ16 | 1300 | 800 | 970 | 1250 | 500 | | MGH(Z)-100 | MT(Z)100 | 7.0 | 14340 | Φ28 | Φ16 | 1300 | 850 | 1170 | 1250 | 500 | | MGH(Z)-125 | MT(Z)125 | 9.32 | 19190 | Φ28 | Φ16 | 1300 | 850 | 1420 | 1250 | 500 | | MGH(Z)-160 | MT(Z)160 | 11.5 | 24090 | Φ28 | Φ16 | 1300 | 850 | 520 | 1250 | 500 | | MGH(Z)-28 | MT(Z)28 | 1.77 | 2730 | Φ12 | Φ10 | 680 | 610 | 520 | 570 | 400 | | MGM(Z)-36 | MT(Z)36 | 2.4 | 3560 | Φ16 | Φ10 | 880 | 680 | 470 | 840 | 490 | | MGM(Z)-50 | MT(Z)50 | 2.98 | 4280 | Φ22 | Φ12 | 960 | 680 | 520 | 910 | 370 | | MGM(Z)-64 | MT(Z)64 | 3.95 | 5690 | Φ22 | Φ12 | 1060 | 680 | 670 | 1025 | 400 | | MGM(Z)-80 | MT(Z)80 | 5.0 | 7330 | Φ28 | Φ16 | 1300 | 750 | 670 | 1260 | 420 | | MGM(Z)-100 | MT(Z)100 | 5.73 | 8210 | Φ28 | Φ16 | 1300 | 800 | 770 | 1250 | 500 | | MGM(Z)-125 | MT(Z)125 | 7.6 | 11450 | Φ28 | Φ16 | 1300 | 850 | 970 | 1250 | 500 | | MGM(Z)-160 | MT(Z)160 | 8.95 | 14460 | Φ28 | Φ16 | 1300 | 850 | 1420 | 1250 | 500 |
|
1. Nominal conditions of refrigerating capacity and power: MGH: -5ºC/50ºC; MGM: -15ºC/50ºC;
2. Power source: 380V/50HZ;
3. Refrigerant: R404A for HGZ and MGZ units. |
Application
1.Used for heat transfer in cold storage and all kinds of low temperature systems
2.Used for the process of hypothermia food producing
3.Used for energy recovery and low temperature system devices
4.Used for industry and commerce air conditioning system
5.Used for vehicle and vessel etc transportation devices Picture:
Contact Name: Alina
Tel: 0086 021 35324169-207
Mob: 18201862851
Shanghai Shenglin is a professional supplier in China specializes in refrigeration units and parts. Now we have two factories. One is mainly manufacturing condensers and evaporators, the other one is mainly manufacturing central air conditioners like roof-top air conditioners, precision air conditioners and air handing units. Both of our factories are ISO certificated.
Our condensers and evaporators can be widely used in air conditioners, heat pumps, fan coils, air handing units, drinking machines, ice makers, dehumidifiers, laser machines, welding machines and other area. We can not only manufacture copper pipe condensers and evaporators, but also manufacture stainless steel pipe and aluminum pipe condensers and evaporators.
Our rooftop air conditioners are easy to be installed and maintained. As they are installed on the top roof, so they will not spare the room space. They are weather proof and have high efficiency.
Our precision air conditioner can control temperature in ± 1ºC and humidity in ± 5%. It can be used in data center and telecom base station. Most parts are world famous brand.
Our products have been exported to Europe, North of America, Middle East, South of Africa and southeast Asia.
We sincerely welcome customers all over the world to visit our company and set up business relationship for mutual benefit.
