High Performance Soft Pack Battery
Lithium Thionyl Chloride Battery (3.6 V)
The selected materials and the manufacturing process of a high-temperature Li-SOCl2 battery are different from those of ordinary batteries. A steel shell and a cover group both have a high-temperature structure, so the high-temperature Li-SOCl2 battery can avoid the phenomena of discharge, heaved bottoms, explosion and combustion while working in high-temperature environments, and has high safety performance.
Model
| MODEL | IEC | Nominal Voltage | Max. Dimension | Weight | Standard | Continuous | Operating | Terminate |
| Capacity/Current | Discharge/Current | Temperature | Voltage |
| (V) | (mm X mm) | (g) | (mAh / mA) | (mA) | oC | (V) |
| CP224035 | -- | 3.0 | 2.2X40X35 | 5 | 480/10 | 150 |
-20ºC~+60ºC |
2.0 |
| CP225040 | -- | 3.0 | 2.2X50X40 | 7 | 750/10 | 200 |
-20ºC~+60ºC |
2.0 |
| CP254442 | -- | 3.0 | 2.5X44X42 | 6.5 | 750/10 | 300 |
-20ºC~+60ºC |
2.0 |
| CP224147 | -- | 3.0 | 2.3X42X48 | 6.5 | 750/10 | 200 |
-20ºC~+60ºC |
2.0 |
| CP305050 | -- | 3.0 | 3.1X50X51 | 13 | 1500/10 | 600 |
-20ºC~+60ºC |
2.0 |
| CP502440 | -- | 3.0 | 5.1X24X42 | 9 | 1200/10 | 400 |
-20ºC~+60ºC |
2.0 |
| CP502525 | -- | 3.0 | 5.0X25X25 | 4.5 | 550/10 | 200 |
-20ºC~+60ºC |
2.0 |
| CP504644 | -- | 3.0 | 5.1X46X45 | 17.5 | 2300/10 | 1200 |
-20ºC~+60ºC |
2.0 |
| CP505050 | -- | 3.0 | 5.1X50X51 | 23 | 3000/10 | 1500 |
-20ºC~+60ºC |
2.0 |
| CP603450 | -- | 3.0 | 6.0X34X50 | 18 | 2300/10 | 1200 |
-20ºC~+60ºC |
2.0 |
| CP7839109 | -- | 3.0 | 7.8X39X109 | 63 | 10000/10 | 3000 |
-20ºC~+60ºC |
2.0 |
| CP9V | -- | 9.0 | 17X26X48.8 | 30 | 1200/10 | 400 |
-20ºC~+60ºC |
2.0 |
Applicants:
1. Civilian field: AMR of common instruments and CMOS circuit boards
2. Various smart meters: smart electric meters, water meters, heat meters and gas meters
3. Memories and standby power supplies: memory backup, clock power supplies and data backup power supplies
4. Radio alarm equipment/sensors: smoke alarms and temperature monitors
5. Remote monitoring systems: positioning devices and marine telemetry systems
6. Automotive electronics: tire pressure monitoring systems
7. Industrial field: automation instrumentations and equipment, oil wells, mines, medical equipment, burglar alarm, wireless communication, sea survival, etc.
8. Modern national defense and military fields: aviation, spaceflight, marine electronics, air-sea-land weapons, etc.
Characteristics:
1.High and stable working voltage
The standard voltage is 3.6V, and the working voltage is kept obviously stable in the whole service life; and more than 90 percent of battery capacity is output on a high-voltage platform with unchanged voltage.
2.Wide operating temperature range
It can be used at the temperature of -60ºC to 150ºC.
3. Longer storage life and higher reliability
It has a quite low self-discharge feature (the annual self-discharge rate is less than or equal to 1%), and adopts stainless steel shell and metal-glass sealing airtight welding structure, so the guarantee period of the battery is proved to be more than 10 years at room temperature.
4. High safety and non-pollution
It does not contain heavy metals such as mercury, cadmium and lead, so the environmental hazard is avoided.
