Product Discription:
1. 4.3 inch resistive touch screen+TFT
2. High brightness
Product Drawing:
Product Parameter:
Size:4.3"(2)
Part number:8940017082
Lens size(mm):105.5*67.2*0.7
Sensor size(mm):103.5*65.2*0.7
Total thickness,without foam(mm):1.6
Active area(mm):96.04*54.86
Independent key:None
View area(mm):96.04*54.86
Surface hardness(mm):≥7H
Resolution ratio:480*272
Linearity(mm):±1.0(±1.5)
Touch point:5
Working voltage:2.8-3.6V
Interface I2C :1.VSS 2.VDD 3.SCL 4.NC 5.SDA 6.NC 7.RST 8.WAKE 9.INT 10.VSS
Power (VDD=2.8V):Normal operation :6mA Monitor mode:4mA Sleep mode:0.03mA
Transmittance(%):≥90
Haze value(%):<0.1
Operation temperature: -20°~70°
Storage temperature: -30°~80°
Product Advantages:
1. The type of touch panel can be customize. Capative and resistive screen are both available.
2. 4.3'' and 7'' TFT can be customize for high brightness back light. Visiable under the sun light.
3. Provide the CTP TOTAL SOLUTION, reduce the R&D time for customers.
|
Size: |
4.3"(2) |
|
Part number: |
8940017082 |
|
Lens size(mm): |
105.5*67.2*0.7 |
|
Sensor size(mm): |
103.5*65.2*0.7 |
|
Total thickness,without foam(mm): |
1.6 |
|
Active area(mm): |
96.04*54.86 |
|
Independent key: |
None |
|
View area(mm): |
96.04*54.86 |
|
Surface hardness(mm): |
≥7H |
|
Resolution ratio: |
480*272 |
|
Linearity(mm): |
±1.0(±1.5) |
|
Touch point: |
5 |
|
Working voltage: |
2.8-3.6V |
|
Interface I2C : |
1.VSS 2.VDD 3.SCL 4.NC 5.SDA 6.NC 7.RST 8.WAKE 9.INT 10.VSS |
|
Power (VDD=2.8V): |
Normal operation :6mA Monitor mode:4mA Sleep mode:0.03mA |
|
Transmittance(%): |
≥90 |
|
Haze value(%): |
0.1 |
|
Operation temperature: |
-20°~70° |
|
Storage temperature: |
-30°~80° |
|
|
