| Prod Model: |
ft |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Fan: |
220V 380V |
| Certification: |
CCC |
| Electric Current Type: |
AC |
Product Description
Features:
The outline border adopt advanced automatic process, more accuracy, material adopt zinc coat and zinc plate
2. The aluminum metal alloy of the high strength hub, adopt aviation aluminum magnesium metal alloy, light weight, high strength, good tensile
3.Strap adjust automatically, no need manual adjustment during lifetime
4. Shutter adopt special push-pull, open- close device, ensure shutter totally open and close, windproof, rainproof and dustproof
5. Newly punch forming fan blade, reasonable angel and reach the max. air flow, mini. Noise
6. Double bracing (E style) belt transporter, Europe industry motor standard
7. Safety net easily tear down
8.strictly quality test process: noise test, vibration test, concentric performance test, fan blade turning speed test, input air test and vehicle efficiency test
9. Special motor hole wind shield, avoid wind losing to reach the best wind suck effect
For the fan size, can customize from client.
Specification
Blade diameter
(mm)
Blade rotational speed rpm
Motor rotational speed rpm
Air flow
(m3/h)
Total pressure
(pa)
Noise decibels
Import
power
(w)
Rated voltage
(v)
Size
(mm)
FT-500
500
620
≥1400
14000
55
≤70
370
380
680*620*370
FT-710
710
560
≥1400
18000
55
≤70
370
380
800*800*370
FT-750
750
560
≥1400
24000
55
≤70
550
380
900*900*370
FT-900
900
560
≥1400
28000
60
≤70
550
380
1000*1000*370
FT-1000
1000
560
≥1400
30000
60
≤70
750
380
1100*1100*370
FT-1100
1100
400
≥1400
35000
60
≤70
750
380
1220*1220*370
FT-1270
1270
325
≥1400
39000
60
≤70
1100
380
1380*1380*370
FT-1400
1400
325
≥1400
45000
60
≤70
1100
380
1530*1530*370
