2X1450W@8ohm FP7000--2X2350W@8ohms FP14000 FP Series 2CH PRO Audio Power Amplifiers, PA Line Array Speakers Powered AMPS Audio
1. Touring Condition Stereo Power Amplifier
2. Digital Audio Power Amplifier
3. Fp Series 2 Channel PRO Audio Power Amplifiers
Applications
1>. Arenas, Cinema
2>. Convention Centers
3>. Medium or large Ballrooms
4>. Perfect for corporate
5>. Theaters Music
6>. Club or Church
7>. Concert reinforcement
Specifications:
|
FP7000--FP14000 Stereo Switching Power Amplifier ( CE Certification ) |
|
ITEM |
FP7000 |
FP9000 |
FP13000 |
FP14000 |
|
Output Power |
20-20kHz, 1W with 1 khz |
|
8ΩStereo Power(RMS) |
1450WX2 |
1600WX2 |
2350WX2 |
2350WX2 |
|
4ΩStereo Power(RMS) |
2800WX2 |
3000WX2 |
4400WX2 |
4400WX2 |
|
2ΩStereo Power(RMS) |
3500WX2 |
4500WX2 |
6500WX2 |
7000WX2 |
|
8ΩBridged Power(RMS) |
5600W |
6000W |
8800W |
8800W |
|
4ΩBridged Power(RMS) |
7000W |
9000W |
13000W |
14000W |
|
Frequency Response(+o/-0.3dB,1W/8Ω) |
20 Hz - 34 kHz |
|
THD 20 Hz - 20 kHz for 1 W |
<0.1% |
|
Signal-to-Noise Ratio |
>112 dBA |
|
Channel separation (Crosstalk) at 1 kHz |
>70 dB |
|
Input Connectors (per channel) |
3-pin XLR, electronically balanced |
|
Output Connectors (per channel) |
Binding Posts 2-pole |
|
Class |
TD |
|
TourClass Protection |
AutoRamp,short cricuit, DC voltage, turn-on/off transient,current nrush |
|
Operating voltage |
130-265 V / 65-135 V selectable |
|
Voltage Gain(dB) |
23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
|
Input impedance |
20 Kohms |
|
Level adjustment (per ch.) |
Front-panel potentiometer, 31 position detented from -inf to 0 dB |
|
Dimensions (W×H×D) |
483×88×396mm |
|
Packing dimension |
580×180×560mm |
|
Net weight(kg) |
13 |
|
Gross weight(kg) |
18 |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
