| Prod Model: |
R22(9K-12K) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling & Heating: |
60Hz |
| R22: |
R410A |
| Inverter: |
Cooling Only |
| Model: |
Indoor Model Outdoor Model |
| Type: |
Fixed-frequency Air Conditioner |
| Capacity: |
9000-12000 BTU |
| Certification: |
BEB |
| China Energy Efficiency Standard: |
Level 1 |
| Cooling/Heating: |
Cooling/Heating |
| Power Source: |
Electrical |
Product Description
Construction Futures
1. High performance cooling system
2. Low noise
3. Powerful cooling and strong wind
4. 24 hour ON/OFF timer
5. Exquisite design and attractive appearance
| Model No. | indoor model | SSCN-09VA | SSCN-09HA | SSCN-12CA | SSCN-12HA |
| outdoor model |
| Power&Inveter type |
| Power supply | V-,Hz,Ph | 220-240,50,1 | 220-240,50,1 | 220-240,50,1 | 220-240,50,1 |
| type Universal Product |
|
|
|
|
|
| Capacity |
| Cooling(rated) | Btu/h | 9000 | 9000 | 12000 | 12000 |
| W | 2600 | 2600 | 3500 | 3500 |
| Heating(rated) | Btu/h | / | 9500 | / | 12500 |
| W | / | 2800 | / | 3700 |
| Electrical |
|
|
|
|
|
| Power input: | Cooling W | 808 | 808 | 1090 | 1090 |
| Heating W | / | 770 | / | 1010 |
| Operating current(A) | Cooling A | 3.5 | 3.5 | 4.7 | 4.7 |
| Heating A | / | 3.4 | / | 4.4 |
| Performance |
| EER | W/W | 3.22 | 3.22 | 3.21 | 3.21 |
| COP | W/W | / | 3.63 | / | 3.66 |
| Energy Rate |
| A | A/A | A | A/A |
| Air Flow Volume(m3/h) | Indoor | 550/450/320 | 550/450/320 | 700/570/460 | 700/570/460 |
| Sound Power | Indoor(Hi) | 41/37/29 | 41/37/29 | 43/38/31 | 43/38/31 |
| Noise Level(dB(A)) | outdoor | 55 | 55 | 56 | 56 |
| Dimension&Weight&Piping Size |
| Net Dimension(mm) | Indoor(W*H*D) | 745x250x188 |
| Outdoor(W*H*D) | 700x530x252 |
| Net Weight(kg) | Indoor/Outdoor | 8/27 | 828 | 8/37 | 8/37 |
| Packing Dimension(mm) | Indoor(W*H*D) | 820x330x270 |
| Outdoor(W*H*D) | 910x630x370 |
| Gross Weight(kg) | Indoor/Outdoor | 10/30 | 10/31 | 10/40 | 10/40 |
| Piping Size(mm(inch)) | Liquid | 6.35(1/4) | 6.35(1/4) | 6.35(1/4) | 6.35(1/4) |
| Gass | 9.52(3/8) | 9.52(3/8) | 9.52(3/8) | 9.52(3/8) |
| Applicable area&Stuffing Quantity |
| Applicable Area(m3) |
| 10-18 | 10-18 | 16-22 | 16-22 |
| Stuffing Quantity(Set) | 20`/40`/40`HQ | 98/225/235 | 98/225/235 | 95/215/225 | 95/215/225 |
