Specifications:
Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5e requirements
Meet TIA-EIA TSB-40
Meet ISO/ICE Generic Cabling Standard 11801
Meet ISO/IEC Generic Cabling Standard EN50173
Angle:180 degree
Termination:110&Krone Type
Electical:
Acccording to UL 1863
Current rating:1.5 AMP Max
Voltage rating:150 Volts
Contact resistance:20 m-ohm
Dielectric Withsand Voltage:1000V AC RMS. 60Hz 1min
Materials:
Housing: PC UL94V-0
IDC: PC UL94V-0.Accept 22-26 AWG Solid Wire
PCB:FR4 1.6MM(0.04″)thickness.2 layers
Contact: PC UL94V-0, 0.45MM(0.018″)Diameter Phosphor bronze with 3U” to 50U” gold plating on contact area
