Product parameters:
Brand name:SDL or OEM
Model number:MS-KCN0.1
Dimension: 100x77x26mm
Weight: 236g
Capacity: 10400 mAh
Socket Type: USB
Input: 5V/2A
Output: 5V/2A 9V/1.67A 12V/1.25A
Color: Blue, Green,Yellow,Coffee,Rose
Certifications: CE FCC RoHS
Protections: yes
Life cycle: 500 times
Short cut protection: yes
Quality: good
Case material: ABS
Warranty: 12 months
Compatible Device: Cell phone,ipad, GPS, PSP,Digital camera
Remaks:
Payment terms:T/T,Paypal,Western Union
MOQ:100pcs
Delivery time:within 3-7 days for samples after payment;within 20 days for bulk order after payment
Product features:
CE,FCC,RoHs international certification, built-in rechargeable insurance with overshoot protection, charging safety guarantee.
support Qualcomm QC2.0 charging standard, support 5V/2.4A, 9V/1.2A, 12V/1A charging mode. It can automatically determine whether the charging device supports fast charge, and automatically adjust the output for the device's required voltage. If the charging device does not support the fast charge, it will only output 5V and to ensure that the device can be charging safely.
While also compatible with BC1.2 charging standard, as well as Apple, Samsung and other brands of proprietary protocols, supporting DCP charging mode device. Intelligent identify all mobile phones, tablet Pcs, etc.to ensure that the charging device's charging current can be maximized,improve charging efficiency.
Features list
1. Support Qualcomm QC2.0 charging protocol, support 5V/2.4A, 9V/1.2A, 12V/1A charging mode.
2.Fully support BC1.2 charging standard, support DCP mode charging (D+, D- short circuit).
Support Apple's series product of charging recognition, support Apple "2727" 2.4A charging mode.
Support Samsung's series product of charging recognition, support Samsung 1212 charging mode.
3. With automatically discharge and load detection function, the discharge conversion efficiency can reach more than 90%.
4. 5V/2A high efficiency PWM mode charging, the highest efficiency is more than 89%.
5.4pieces of LED lights show the remaining capacity of the battery, and can indicate the charge-discharge,overcurrent, short circuit and other abnormal phenomena.
6. Independent hardware battery protection, to prevent the battery over-charging, over-discharge, over-current, short -circuit, and so on, the security is higher than before.
7. Support load detection function.
8. Support while charging side discharging, prohibit charging and discharging at the same time.
9. With functions of charging and discharging over temperature protection.
10. Ultra low standby power consumption, standby current is only 10 uA.
Application:
Fully compatible with the iphone and match other mobile phones (iphone,Samsung,Sony,HTC,LG,Xiaomi),ipad and other tablet PCs,ipod,PSP games,Bluetooth devices,MP3/MP4 and other digital products for charging.
Charging speed dependes on your device's input voltage and current.
Intelligent IC
Using the word's large-scale circuit supplier Texas Instruments New USB Intelligent Control Chip and charge and discharge chips.Not only provides 9 circuit protection,but also to enhance the charge-discharge efficiency.
