Phonebook Dialer and Messaging Android Smart Bluetooth Mobile Phone WatchThe whole machine instiutions to introducePower on or off key/HOME key ~Long press this button to start power on/off, Short Press to return to the standby interface.
Back key/Hang up key ~click to back to previous menu or hang up when calling
Volume key~click to pop-up volune adjustment interface
Confirm/answer key~Standby interface click to enter the main menu,confirm key in the main menu, answer key when calling.
Microphone~Don't keep out the hole while calling.
USB port~battery charging.
Speakcr~Don't keep out the hole while calling.
RESET hole~click on this key to achieve the system reset when the watch is abnormal.
Introduce the main menu:According to watch the main function is divded into 4 page
Frist page:Bluetooth,Phonebook,Dialer,Messaging;
Seeond page:Call log, Notification, Music, Remote capture;
Fourth page:Baromemeter, Altimeter, Pedometer, Stopwatch.
Function information :l Bluetooth: Open this function will see the following menu.
1
)Bluetooth dialer ~ search and a matching connection with bluetooth devices
2
)Bluetooth settings ~ Bluetooth can be truned on and off and the machine equipment name
Display
l Phonebook: The watch is connected with the mobile phone will display mobilc phone contacts in the machine (can display 1000)
l Dialer: Watch is connected to the phone can dial
l Messaging: Open this function will see the following menu.This function needs to install the"BTNotification.apk"application for use in mobile phone terminal
1
)Inbox: Show a mobile phone short message
2
)Sent messages: Show a mobile phone short message
l Call log: Open this function will see the following menu
1
)Missed calls ~ Display the missed call, At the same time can call the corresponding contact
2
)Diaicd calls ~ Display the missed call, At the same time can call the corresponding contact
3
)Received calls ~ Display the missed call, At the same time can call the corresponding
Contact
4
)All calls ~ Display mobile phone calls all phone records
l Notification: Can query the QQ / Wechat and other timely news, This function needs to install the "BTNotification.apk" application for use in mobile phone terminal
l Music: Can control the music playing in the mobile phone
l Remote capture: Rcmote on / off mobile phone camera press confirm to complete pictures
l Settings: Open this function will see the follpwing menu
1
)Clock typc ~ For analog and digital clock selection.
2
)Set Time ~ Can set up time.
3
)Set Date ~ Can set up date.
4
)About watch ~ display mobile phone software version information.
l Anti lost: Watch wil shake alarm after keep away from the mobile phone for a certain distance. Open this function will see the follwing menu .
1
)Enable
l Power saving: Open this function the use of the time od the watch will be more durable
l Ringtone: For different state set ringtones, Open this function will see the dollowing menu.
1
)Mute
2
)Vibration
3
)Ring1
4
)Ring2
5
)Ring3
l Barometer: Open this function to display the current atmospheric pressure altitude and the current temperature.
l Altimeter: Calculation of vertical to watch moving downward relative height after a certain distance. Open this function will see the following menu
1
)Cur Alitmeter(m)
2
)Set start altitude ~ Click the menu setting initial height, Then the vertical upwards or
Downward
2
)Relative Alitmeter(m) ~ Display watch the relative height after vertical upward or downward
l Pedometer: Calculation of the walking distance of time (time, minutes, seconds)and the number of kilometers (km). Open this function will see the following menu.
1
)Pedometer ~ After entering the menu then press the mechanical keys trigger timing stars
2
)Last Record ~ Record the minutes of the last walking time and milcage
3
)Step Setting(CM) ~ According to height ratio setting step distance
l Stopwatch: Open this function can be timing.
| System Physical Standard Configuration |
| Type | Details | Descriptions |
| Product Form | Product Form |
|
| Dimensions | 40*47*9.9mm |
| Weight | 44g |
| LCD Panel | Screen Size | 1.44" |
| Screen Resolution | 128*128 |
| Touch Panel | Touch Module | yes |
| Battery | Type | Lithium-ion polymer battery |
| Capacity | 3.7V/230mAh |
| System hardware configuration(): |
| Type | Details | Descriptions |
| CPU | Type | MTK6260-ARM7 |
| Speed | 360MHz |
| RAM | SRAM | MTK6260(Built-in)-32mb |
| ROM Flash | NOR Flash | MTK6260(Built-in)-32mb |
| Camera | Front Facing | NO |
| Speaker | Built-in | 8Ω/0.7W speaker x 1 |
| MIC | Built-in | Yes |
| G-sensor | Built-in | Yes |
| GPS | Built-in | NO |
| Bluetooth | Built-in | MTK6260(Built-in)-BT3.0 |
| BT() | Built-in | Yes |
| 3G/2G | Internal | NO |
| Interface Configuration(): |
| Type | Details | Descriptions |
| Memory card socket | External memory | NO |
| USB interface(USB ) | Data transfer supportive | Micro USB |
| Headphone jack | Music output | NO |
| DC connector | Power | Micro USB (with Cap) |
| Keys | Tack Switch | POWER ON or Back |
| Software Configuration |
| Type | Details | Descriptions |
| Software Feature | Operation System | Nucleus |
| Phone Book | 1500 |
| Phone Call | Support (Load Speaker and Receiver Mode) |
| SMS | Support (need APP) |
| MMS | Push Icon (need APP) |
| Time Sync. | Support |
| Call History | Support access and call |
| Music Player | Support |
| Set Time/Date | User-defined |
| Alarm | Support five Set |
| Stopwatch | Support |
| Barometer | Support |
| Pedometer | Support |
| Thermometer | Support |
| Language | Default China and English(Multi language support) |
Smart Phone
Information notifcation | Gmail, CNN APP, ZAKER
LINE, Facebook, Instugrate,Facebook Message
QQ,V Message,
360 etc |
| Necessary Accessories: |
| Type | Details | Descriptions |
| Power adapter | Standard Charger |
|
| USB data cable(USB) | Standard Micro USB Cable |
|
|
|
|
