Function specification
Operating System: X86 windows, X86 Linux
Motherboard : Android A20 1.2-1.5G dual core
CPU : Android A20 1.2-1.5G dual core
Memory : DDR3-1G
Hard Disk drive : INAND 8GB
Storage port : USB, SD card, SATA port hard disk storage
OS : Android 4.2.2
WiFi : Yes, inbuild WiFi(802.11b/g/n); 3G/GPS/Bluetooth(optional)
Output : HDMI, VGA,LVDS
Input : inbuild AV port
Other ports : USB*4,Micro SD*1, RJ45*1, SATA*1,PCI*1
Speaker : inbuild 2 speakers (10W/pc )
Support video : MPEG1/MPEG2/MPEG4/AVI/VOB/MOV/WMV/DIVX/RM/RMVB, support super HD 2160P video
Support picture : JPG/JPEG/GIF/PNG/BMP
Support Flash : flash 11, SWF/FLV/F4V
Support TXT : TXT/WORD/EXCEL/PDF
Support Website : HTML/ASP/JSP/PHP
Support RSS : Internet RSS title and text, flip over/page turning
Long-distance control : monitoring the terminal display image in real time
Long-distance wake up : Wake up the off terminal end by the current network
Timer : Set time on/off auto
Image rotate : support 90°,180°,270° image rotate
Display zone : Support more than 30 individual display zones
Software upgrade : Support upgrade software by LAN or SD card
Specification |
Model |
D650D |
panel size |
65inch |
Dimensions |
1540x917x97mm |
Body Material |
Metal case SPCC |
resolution of PBC |
480P/720P/1080P |
Maximum resolution |
1920x1080 |
Brightness |
600 cd / m2 |
Display color |
16.7M |
Contrast |
1000:1 |
Viewing Angle |
178° |
Response time |
5ms |
Life(hrs) |
>60,000(hrs) |
Color |
white ,black ,can be customized |
Input Power Voltage |
AC100-240V |
Working Temperature |
-20°C~+80°C |
Speakers |
2×5W(9Ω) |
Program Input Port |
USB 2.0 x 2 |
Built-in Flash Memory |
DDR3 1333MHZ 4GB |
Signal Input Port |
VGA,HDMI,Audio (3.5mm) |
Power Consumption |
270W |
Supported Media Format |
Video: All Formats (1080P Full HD) |
Picture: JPG,GIF,BMP,PNG |
Audio: All Formats |
Timer On/Off |
Support (Set by daily or weekly) |
Scrolling Test |
Support |
Split Screen |
Support |
AD Playlist Editor |
Support (software free of charge, sync with LCD |
digital signage via USB flash drive to achieve different functions) |
Internet Control |
LAN, WIFI,3G (Optional) |
(work with software) |
Software |
Optional (digital signage software to control LCD display via internet to |
achieve different functions) |
Accessories |
IR Remote Controller, CD ,Key |
