Product Description
Control System:
1. Intelligent & LCD display temperature controller, blue-ray background light, easy using;
2. Inside temperature can be set freely from -10° C~-40° C of freezer chamber, 2~10° C for refrigerator;
3. Safety alarm system included high or low temperature, power failure, Low battery level, door opening, filter blocking, system failure and etc;
4. Machine startup delay, power off protection;
5. 72 hours battery backup for printer and controller display.
Structure Design:
1. Independent chamber & refrigerate system for two chamber of Freezing & Refrigerating.
2. Photocatalysis of TiO2 nanomaterials catalyst effectively kill bacteria in the air;
3. External painted steel, inner ABS, exquisite beauty, easy to clean;
4. Front opening lockable door with full height handle;
5. Upper 4 PCS of adjustable shelves, lower 3 PCS of drawers;
6. 90mm foaming insulation to ensure the stability of temperature
7. PT-100 platinum resistance sensors which is very sensitive to the temperature changing;
8. keyboard lock and password protected to prevent the adjustment of the operating parameters;
9. Fitted with 4 PCS casters & level feet for easy moving;
10. Safety door lock, dual-door design;
11. EPS Emergency power supply, temperature recorder, warning lamp is optional.
Refrigeration System:
1. Adopted DANFOSS compressor, EBM fans from Germany;
2. Independent chamber & refrigerate system for two chamber of Freezing & Refrigerating;
3. Upper refrigerator, lower freezer, double door double loop design;
4. CFC-FREE refrigerant ensure environmental protection & safety.
5. Certificate: CE certificate, ISO9001, ISO14001, ISO13485
|
Model |
MR-DF-FL253 |
|
Total Capacity |
253L |
|
Freezer Capacity |
99L |
|
Refrigerator Capacity |
154L |
|
Freezer temp. range |
-10°C ~ -40°C |
|
Refrigerator temp. range |
2°C ~ 10°C |
|
Compressor |
2 pcs independent |
|
Compressor brand |
Danfoss |
|
Fan motor |
EBM from Germany |
|
Evaporator |
D-form copper tube |
|
Shelves (Upper) |
4 pcs |
|
Drawers (Lower) |
3 pcs |
|
Inner material |
ABS |
|
External material |
Painted steel board |
|
Door Lock |
Yes |
|
Freezer size |
397×368×414mm |
|
Refrigerator size |
397×368×781mm |
|
Dimensions (D*W*H) |
624×604×1775mm |
|
Alarm system |
Visual & Audio |
|
Output Power |
400W |
|
Voltage |
220V/50Hz (110V/60Hz) |
|
Refrigerant |
CFC- R134a (R507) |
|
Climatic |
N |
|
NW/GW |
75/85 kg |
