| Prod Model: |
CT-8012 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black and White |
| Noise: |
<95dB |
| Application: |
Club, Stage,Karaoke |
| Certification: |
ISO9001:2008 |
| THD: |
0.005%-0.01% |
Product Description
1200W Transformer-Based Professional Power Amplifier(CT-8012)
Technical data & Introduction:
Rated Output
2*1200W, 8 ohm
2 *1800W, 4 ohm
Frequency Range: 20Hz-20KHz +0,-0.5dB
Signal to Noise ratio: 98 dB
Input Sensitivity: 0.7V/1V/1.4V
THD < 0.08%
Input impedance: 47KΩ
Peak Power: 5400W
Machine Dimensions: 690W×435D× 120(mm)H
Advantage:
1)Input Sensitivity is 0.7V/1V/1.4V,so it can change the sensitivity as you need.
2)Class H circuit.
3)Adopt SMT technology,it will little mistake in the amplifier when producing.
4)The transistor is ON Semiconductor transisitor.
5)DC protection,Overload protection,Overheat protection,Short circuit protection,Soft start,
6)We have passed CE,CE-LVD,ISO9001,FCC,ROHS.
Rear Panel Pictures as follows:
Inside picture
Suit for :
1) Arena and stage
2)Convention Centers
3)Medium or large Ballrooms
4)conference rooms
5)Theaters Music
6)Club or Church
7)Concert and music group
MODEL | CT-8012 | CT-8010 | CT-8008 | CT-8006 | CT-8004 |
| Rated output power 8 Ω | 1200W × 2 | 1000W × 2 | 800W × 2 | 600W × 2 | 400W × 2 |
| Rated output power 4 Ω | 1800W × 2 | 1500W × 2 | 1300W × 2 | 900W × 2 | 600W × 2 |
| Frequency response | 20HZ-20KHZ ( +0, -0.5dB ) |
| Signal-to-noise ratio | 98dB | 96dB | 96dB | 95dB | 92dB |
| Input sensitivity | 0.7V/1.0/V1.4V | 0.7V/1.0/V1.4V | 0.7V/1.0/V1.4 | 0.7V/1.0/V1.4V | 0.7V/1.0/V1.4V |
| THD | ≤ 0.08% | ≤ 0.08% | ≤ 0.08% | ≤ 0.08% | ≤ 0.08% |
| Input impedance | 47K Ω | 47K Ω | 47K Ω | 47K Ω | 47K Ω |
| Supply Rated output pawer | 5400w | 4500W | 3900W | 2700W | 2100W |
| Exchange insurance | 25A | 20A | 15A | 10A | 8A |
| Net weight | 29.5KG | 27KG | 25KG | 21KG | 19KG |
| Package size mm | 690W*435D*120H 480W × 490D × 110H mm |
| Package Package size mm | 740W*590D*193H 600W × 580D × 190H mm
|
Guangzhou YunQiang Electronics Co., Ltd. is a professional audio manufacturer which has R& D, Production department, Marketing Dept., and Technical and service Dept.,
The main products include: Power Amplifier, Karaoke amplifier, Professional Speaker, Karaoke speaker, Sound Mixer, Audio processor and Conferencing systems.
Nowadays, in professional sound industry, more and more people are seeking for amplifiers with light weight, high power output, high sound quality and high stability.
To get good sound quality, we should have high quality components. And to ensure the stability, we must solve the problem of heat dissipation. Now, we have this amplifier FP14000, FP10000Q, FP-8000Q. Our FP14000, FP10000Q, FP-8000Q is Class TD switching amplifier fixed with NOVER (from UK) power capacitors, ON-Semi power transistors other high quality electronic spare parts. Professional circuit design and actual copper heat sink with better structure make fast heat dissipation possible. And fast heat dissipation contributes to high stability of the amplifier. Once you have our amplifiers at your hands, open the chassis, you will find artwork and detail difference. The swich power amplifier can be used to drive line array loudspeaker systems in touring, living show and other applications with high requirement on sound quality and stability.
Since the foundation of our enterprises, we have been concentrating on designing new products, doing research on new sound technology, training our staff, as well as improving our quality to products and management system. And now we have had a unique management experience, advanced production equipment, abundant design capability, and the large marketing network and after-sales service system.
Now we have passed newest CE, FCC, RoHS, SGS, CCC, ISO9001 on March, 2015.
